Description
Overview
The Bently Nevada 330101‑00‑59‑10‑01‑05 proximity probe is part of the 3300 XL 8 mm transducer family, engineered for precise shaft vibration and position measurement in high‑performance rotating machinery. This model incorporates updated mechanical and electrical design features that enhance stability, reduce noise, and improve long‑term reliability compared with earlier probe generations.
Technical Specifications
| Parameter |
Specification |
| Model |
330101‑00‑59‑10‑01‑05 |
| Product Type |
3300 XL 8 mm Proximity Probe |
| Brand |
Bently Nevada |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| Thread Type |
3/8‑24 UNF |
| Cable Length |
1.0 m standard |
| Connector |
Miniature coaxial ClickLoc with protector |
| RFI/EMI Immunity |
CE‑approved, high‑resistance design |
| Mounting Footprint |
Compatible with legacy 4‑hole Proximitor layouts |
| Electrical Isolation |
Integrated mounting base isolation |
| Certifications |
CSA, ATEX, IECEx |
| System Compatibility |
3300 XL Proximity Transducer System, TSI |
| Condition |
New |
| Origin |
USA |
| MOQ |
1 |
| Availability |
In Stock |
| HS Code |
8537101190 |
Functional Description
The 330101‑00‑59‑10‑01‑05 probe is designed to measure the distance between the probe tip and a conductive target surface, typically a rotating shaft. This measurement supports vibration diagnostics, shaft position tracking, and machinery protection functions.
Its compact mechanical design allows installation in dense panel layouts or DIN‑rail assemblies without requiring additional isolation hardware. The integrated mounting base provides electrical isolation, simplifying installation and reducing component count.
Enhanced RFI/EMI immunity enables the probe to operate reliably in fiberglass housings or electrically noisy environments without requiring shielded conduit. This reduces installation complexity and ensures stable signal quality.
The ClickLoc connector ensures a secure, vibration‑resistant connection, while the probe’s rugged construction and global certifications make it suitable for hazardous or regulated industrial environments.
Application Scenarios
-
Turbine and compressor shaft vibration monitoring
-
Pump and motor displacement measurement
-
Gearbox condition monitoring
-
High‑density control panel installations
-
Environments requiring high RFI/EMI immunity
FAQ
Q: What proximitor does this probe pair with? A: It is designed for use with 3300 XL Proximitor sensors matched to the 8 mm probe series.
Q: Can this probe be installed in non‑metallic housings? A: Yes. Its enhanced RFI/EMI resistance allows installation in fiberglass or composite housings without signal degradation.
Q: Does the probe require additional isolation hardware? A: No. The mounting base includes built‑in electrical isolation.
Q: Is the connector secure under vibration? A: The ClickLoc connector locks in place to prevent loosening in high‑vibration environments.
