Description
Overview
The Bently Nevada 330101‑00‑41‑15‑12‑05 proximity probe is part of the 3300 XL 8 mm transducer system, engineered for high‑accuracy shaft vibration and position measurement in fluid‑film bearing machinery. Designed to meet API 670 (4th Edition) requirements, this probe delivers stable, linear, and repeatable performance in demanding industrial environments.
Key Characteristics
-
8 mm eddy‑current probe for displacement and vibration monitoring
-
Fully compliant with API 670 mechanical and performance criteria
-
Suitable for static position, dynamic vibration, Keyphasor, and speed measurement
-
Interchangeable with all 3300 XL extension cables and Proximitor sensors
-
Backward‑compatible with legacy 3300 5 mm and 8 mm components
-
FluidLoc cable construction for oil‑resistant performance
-
Miniature ClickLoc connector for secure, vibration‑resistant mating
-
Certified for hazardous‑area use (CSA, ATEX, IECEx)
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330101‑00‑41‑15‑12‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
3/8‑24 UNF |
| Case Length |
1.5 m |
| Cable Length |
1.2 m |
| Cable Type |
FluidLoc oil‑resistant cable |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Principle |
Eddy‑current displacement |
| Output |
Voltage proportional to probe‑target gap |
| Certifications |
CSA, ATEX, IECEx |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| System Compatibility |
3300 XL Proximity Transducer System |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330101‑00‑41‑15‑12‑05 probe is engineered to provide accurate displacement and vibration measurements across a wide operating range. Its sensing element produces a voltage proportional to the distance between the probe tip and the conductive target surface, enabling precise monitoring of shaft behavior in rotating machinery.
The probe’s FluidLoc cable prevents oil migration through the cable interior, improving long‑term reliability in lubrication‑rich environments. The ClickLoc connector ensures a secure electrical interface that resists loosening under vibration, while maintaining low contact resistance.
As part of the 3300 XL system, the probe is fully interchangeable with extension cables and Proximitor sensors, eliminating the need for matched components or field calibration. Its backward compatibility with earlier 3300 series components simplifies system upgrades and mixed installations.
Application Scenarios
FAQ
Q: Is this probe compatible with older 3300 series components Yes. It is fully backward‑compatible with non‑XL 5 mm and 8 mm probes, cables, and sensors.
Q: What advantage does FluidLoc cable provide It prevents oil migration through the cable, improving reliability in lubrication‑rich environments.
Q: Does this probe require matched calibration with its extension cable No. All 3300 XL components are factory‑calibrated for interchangeability.
