Description
Overview
The 330101-00-40-10-02-00 Bently Nevada 3300 XL 8 mm Proximity Probe is a high-precision eddy current sensor designed for vibration and shaft position monitoring in machinery protection systems. Built with a PPS probe tip and stainless-steel housing, it delivers reliable performance in harsh industrial environments where durability and measurement accuracy are critical.
Technical Specifications
-
Model Number: 330101-00-40-10-02-00
-
Product Type: 3300 XL 8 mm Proximity Probe
-
Thread Size: 3/8-24 UNF
-
Probe Tip Material: Polyphenylene sulfide (PPS)
-
Case Material: Stainless steel
-
Operating Temperature Range: -35°C to +120°C
-
DC Resistance: 7.59 ± 0.50 Ω
-
Cable Type: 75 Ω triaxial cable
-
Mechanical Strength: 330 N at probe case, 270 N at cable connectors
-
Calibration Standard: AISI 4140 steel (custom calibration available)
-
Extension Cable Requirement: Not required for one-meter system configurations
-
Weight: 0.06 kg
-
Dimensions: 1.8 × 1.6 × 123 cm
-
System Compatibility: 3300 Proximity Transducer System
-
Compliance: API 670 standards for mechanical configuration and measurement accuracy
-
Origin: USA
-
HS Code: 8537101190
Key Features
-
High mechanical strength for secure installation
-
PPS probe tip with stainless-steel case for enhanced durability
-
Calibrated for AISI 4140 steel, with customization available
-
Seamless integration into 3300 XL systems
-
Reliable performance across wide temperature ranges
Application Scenarios
The 330101-00-40-10-02-00 probe is widely used in turbines, compressors, pumps, and other critical rotating machinery. It is particularly suited for overspeed detection, tachometer applications, and shaft vibration monitoring where precision and reliability are essential.
FAQ
Q: Does this probe require an extension cable? A: No, it does not require an extension cable in one-meter system configurations.
Q: What material is the probe calibrated for? A: It is typically calibrated for AISI 4140 steel but can be customized for other materials.
Q: Can it be used for tachometer applications? A: Yes, but it is recommended to consult Bently Nevada’s application notes for proper installation.
