Description
Overview
The 330101-00-30-20-12-05 Bently Nevada 3300 XL 8 mm Proximity Probe is a high-performance sensor designed for vibration and shaft position monitoring in critical rotating machinery. Built with advanced mechanical reinforcement and corrosion-resistant connectors, it ensures reliable operation in harsh industrial environments and hazardous areas.
Technical Specifications
-
Model Number: 330101-00-30-20-12-05
-
Product Type: 3300 XL 8 mm Proximity Probe
-
Thread Size: 3/8-24 UNF
-
Cable Length: 1.0 m (3.3 ft)
-
Connector Type: Gold-plated ClickLoc connector, finger-tight installation
-
Pull Strength: 330 N (75 lbf) with CableLoc design
-
Optional Feature: FluidLoc cable to prevent oil/liquid migration
-
Operating Temperature Range: Standard -51°C to +177°C; Extended Temperature Range (ETR) option up to 218°C (probe) and 260°C (extension cable)
-
Weight: 0.08 kg
-
Dimensions: 112 × 1.5 × 1.2 cm
-
System Compatibility: 3300 XL Proximity Transducer System
-
Compliance: API 670 standards for mechanical configuration, accuracy, and linear range
-
Certifications: CSA, ATEX, IECEx approvals for hazardous area use
-
Origin: USA
-
HS Code: 8537101190
Key Features
-
TipLoc molding process for enhanced probe tip-to-body bond strength
-
CableLoc design providing high mechanical pull strength
-
FluidLoc cable option for contamination prevention
-
Gold-plated ClickLoc connectors for secure, tool-free installation
-
Extended temperature range options for extreme environments
-
Certified for hazardous industrial applications
Application Scenarios
The 330101-00-30-20-12-05 probe is widely used in turbines, compressors, pumps, and other fluid-film bearing machines. It is particularly suited for hazardous environments and installations requiring extended temperature tolerance and robust mechanical durability.
FAQ
Q: What is the maximum operating temperature of this probe? A: With the Extended Temperature Range option, the probe can operate up to 218°C and extension cables up to 260°C.
Q: Does this probe require special tools for installation? A: No, the ClickLoc connector design allows secure installation with finger-tight torque.
Q: Can it be used in hazardous environments? A: Yes, it carries CSA, ATEX, and IECEx certifications.
