Description
Overview
The Bently Nevada 330101‑00‑24‑10‑02‑00 proximity probe is part of the 3300 XL 8 mm transducer family, designed for precise non‑contact measurement of shaft vibration and position in rotating machinery. Its mechanical robustness and stable electrical characteristics make it suitable for long‑term use in demanding industrial environments.
Design and Construction
This probe uses a 3/8‑24 UNF threaded body and includes a 1.0‑meter molded cable terminated with a miniature coaxial ClickLoc connector. The connector design prevents accidental loosening and maintains shielding integrity, ensuring consistent signal transmission to the Proximitor sensor.
Compared with 5 mm probes, the 330101‑00‑24‑10‑02‑00 features a thicker encapsulation and reinforced case structure, improving durability in high‑vibration or mechanically exposed installations. The probe is available in armored and unarmored configurations, offering flexibility for different mounting and routing requirements.
Technical Specifications
| Parameter |
Specification |
| Model |
330101‑00‑24‑10‑02‑00 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Type |
3/8‑24 UNF |
| Cable Length |
1.0 m |
| Connector |
Miniature coaxial ClickLoc |
| Measurement Type |
Static position and dynamic vibration |
| System Compatibility |
3300 Proximity Transducer System |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order |
1 unit |
| Product Status |
Active |
| System |
TSI |
Performance Characteristics
The probe produces a voltage output proportional to the distance between the probe tip and the target surface, enabling accurate displacement and vibration measurements. It is suitable for fluid‑film bearing machines and supports Keyphasor reference and speed measurement applications.
The 330101‑00‑24‑10‑02‑00 is fully interchangeable with other 3300 XL components and backward‑compatible with non‑XL 5 mm and 8 mm probes, eliminating the need for matched calibration and simplifying system maintenance.
Application Scenarios
-
Radial vibration and shaft displacement monitoring
-
Axial position measurement on turbines and compressors
-
Keyphasor reference signal acquisition
-
Speed measurement on rotating machinery
-
High‑vibration industrial environments requiring durable probe construction
FAQ
Q: Is this probe compatible with older 3300 series components? A: Yes. It can be used with non‑XL 5 mm and 8 mm probes and cables without requiring matched calibration.
Q: What type of machines typically use this probe? A: Turbines, compressors, pumps, and other rotating equipment with fluid‑film bearings.
Q: Does the probe require a specific Proximitor sensor? A: For optimal accuracy, it should be paired with a 3300 XL Proximitor sensor.
