Description
Overview
The Bently Nevada 330101‑00‑20‑05‑01‑05 proximity probe is part of the 3300 XL 8 mm transducer system, engineered for accurate non‑contact measurement of shaft vibration and position in rotating machinery. Its compact mechanical design and stable electrical characteristics make it suitable for installations requiring short cable lengths and precise monitoring performance.
Design and Construction
This probe features a 3/8‑24 UNF threaded body with a minimum case length of 2.0 inches, allowing secure mounting in a wide range of machine configurations. The 330101‑00‑20‑05‑01‑05 includes a 0.5‑meter molded cable terminated with a miniature ClickLoc connector and connector protector, ensuring a secure, vibration‑resistant electrical interface.
The non‑armored configuration provides flexibility for routing in confined spaces while maintaining full compatibility with 3300 XL extension cables and Proximitor sensors.
Technical Specifications
| Parameter |
Specification |
| Model |
330101‑00‑20‑05‑01‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Type |
3/8‑24 UNF |
| Minimum Case Length |
2.0 in |
| Cable Length |
0.5 m |
| Connector |
Miniature coaxial ClickLoc with protector |
| Measurement Type |
Static position and dynamic vibration |
| System Compatibility |
3300 XL Proximity Transducer System |
| Certifications |
CSA, ATEX, IECEx |
| Weight |
0.1 kg |
| Dimensions |
2 × 1.5 × 112 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Minimum Order |
1 unit |
| Product Status |
Active |
| System |
TSI |
Performance Characteristics
The 330101‑00‑20‑05‑01‑05 supports full interchangeability with other 3300 XL probes, extension cables, and Proximitor sensors, eliminating the need for matched calibration. Its short cable length is ideal for installations where the probe must be mounted close to the Proximitor sensor or where cable routing is restricted.
The probe is certified for hazardous‑area use and maintains stable performance in environments with high electromagnetic interference.
Application Scenarios
-
Turbine, compressor, and generator vibration monitoring
-
Shaft displacement and axial position measurement
-
Installations requiring short probe cable lengths
-
Machinery protection systems using 3300 XL components
-
Predictive maintenance programs in heavy industry
FAQ
Q: What makes this probe suitable for short‑distance installations Its 0.5‑meter cable reduces excess cable routing and improves installation flexibility.
Q: Is this probe compatible with older 3300 series components Yes. It integrates seamlessly with the 3300 XL system and can replace non‑XL probes when installed correctly.
Q: Does the ClickLoc connector improve reliability Yes. It prevents accidental loosening and maintains shielding integrity in high‑vibration environments.
