Description
Overview
The Bently Nevada 330101-00-18-10-12-05 proximity probe is an 8 mm displacement sensor designed for high‑accuracy shaft position and vibration measurement in rotating machinery. As part of the 3300 XL Proximity Transducer System, it provides stable, repeatable output suitable for machinery protection and continuous condition monitoring.
Technical Specifications
| Parameter |
Specification |
| Model |
330101-00-18-10-12-05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
3/8‑24 UNF |
| Cable Length |
1.0 m (3.3 ft) |
| Cable Technology |
CableLoc reinforced design (330 N pull strength) |
| Probe Tip Technology |
TipLoc molded tip bonding |
| Optional Cable Type |
FluidLoc leak‑prevention cable |
| Connector Type |
Gold‑plated ClickLoc connector |
| Certifications |
CSA, ATEX, IECEx |
| System Compatibility |
3300 XL Proximity Transducer System |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
New |
| MOQ |
1 |
| Lead Time |
In stock |
| System |
TSI |
| Status |
Active |
Functional Characteristics
The 330101-00-18-10-12-05 probe incorporates several patented mechanical enhancements to ensure long‑term reliability. The TipLoc molding process secures the probe tip to the body, preventing separation under vibration or thermal cycling. The CableLoc design reinforces the cable‑to‑probe interface, providing exceptional tensile strength for demanding installations.
Gold‑plated ClickLoc connectors maintain low‑resistance electrical contact across the probe, extension cable, and Proximitor sensor, ensuring signal integrity. Optional FluidLoc cables prevent oil migration, making the probe suitable for lubrication‑rich environments.
The probe meets global hazardous‑area certifications, enabling deployment in oil and gas, power generation, and heavy industrial applications.
Application Scenarios
This probe is commonly used in:
-
Turbines and compressors
-
High‑speed pumps and motors
-
Gearboxes and industrial drive systems
-
API 670–compliant protection systems
-
Machinery requiring continuous vibration and displacement monitoring
FAQ
Q: Does this probe require matched calibration with its extension cable? A: No. The 3300 XL system is designed for full interchangeability without bench calibration.
Q: Can this model replace older 8 mm probes? A: Yes. The mechanical and electrical characteristics support direct replacement in most legacy systems.
Q: Is the probe suitable for hazardous environments? A: Yes. It carries CSA, ATEX, and IECEx approvals for use in classified areas.
