Description
Overview
The 330101-00-15-20-12-05 Bently Nevada 3300 XL 8 mm Proximity Probe is a precision-engineered sensor designed for vibration and shaft position monitoring in critical rotating machinery. Its compact design, robust construction, and certified safety approvals make it a reliable choice for industrial environments requiring accurate and durable monitoring solutions.
Technical Specifications
-
Model Number: 330101-00-15-20-12-05
-
Product Type: 3300 XL 8 mm Proximity Probe
-
Thread Size: 3/8-24 UNF
-
Minimum Unthreaded Length: 0.0 in (0 mm)
-
Case Length: 1.5 in (38 mm)
-
Cable Length: 2.0 m (6.6 ft)
-
Connector Type: Miniature coaxial ClickLoc connector
-
Cable Feature: FluidLoc design to prevent oil/liquid migration
-
Probe Body: Molded PPS plastic with thicker encapsulation for coil protection
-
Weight: 0.06 kg
-
Dimensions: 1.8 × 1.6 × 123 cm
-
System Compatibility: 3300 XL Proximity Transducer System
-
Backward Compatibility: Compatible with non-XL 3300 5 mm and 8 mm components
-
Compliance: API 670 standards for mechanical configuration, accuracy, and linear range
-
Certifications: CSA, ATEX, IECEx approvals for hazardous area use
-
Origin: USA
-
HS Code: 8537101190
Key Features
-
Compact probe design for installations with limited space
-
FluidLoc cable prevents contamination from oil migration
-
Rugged PPS encapsulation for enhanced mechanical durability
-
Lightweight construction for easy handling and installation
-
Certified for hazardous environments (CSA, ATEX, IECEx)
-
Fully interchangeable with 3300 XL system components, eliminating calibration requirements
Application Scenarios
The 330101-00-15-20-12-05 probe is ideal for turbines, compressors, pumps, and other fluid-film bearing machines. It is particularly suited for hazardous industrial environments where certified safety compliance and precise monitoring are required.
FAQ
Q: What is the cable length of this probe? A: The probe includes a 2.0 m (6.6 ft) cable.
Q: Does it require calibration during installation? A: No, it is fully interchangeable and does not require bench calibration.
Q: Can silicone tape replace connector protectors? A: Yes, but it is not recommended for applications where the connection is exposed to turbine oil.
Q: Is it compatible with older 3300 series components? A: Yes, it is backward compatible with non-XL 3300 5 mm and 8 mm components.
