Description
Overview
The Bently Nevada 330101‑00‑09‑10‑02‑05 proximity probe is part of the 3300 XL 8 mm eddy‑current transducer system, engineered for precise shaft vibration and position measurement in fluid‑film bearing machinery. Its compact mechanical design and stable electrical characteristics make it suitable for continuous monitoring in demanding industrial environments.
Key Characteristics
-
8 mm eddy‑current probe for displacement and vibration monitoring
-
Designed for use with 3300 XL extension cables and Proximitor sensors
-
Optional connector protectors available for enhanced environmental sealing
-
Lightweight construction for easy installation in confined spaces
-
Fully interchangeable with 3300 XL and legacy 3300 5 mm / 8 mm components
-
Suitable for high‑vibration, high‑temperature industrial applications
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
330101‑00‑09‑10‑02‑05 |
| Probe Type |
3300 XL 8 mm Proximity Probe |
| Thread Size |
Standard 3300 XL probe threading |
| Cable Length |
1.0 m (3.3 ft) |
| Cable Type |
Unarmored coaxial cable |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Principle |
Eddy‑current displacement |
| Environmental Protection |
Optional connector protectors |
| Weight |
0.06 kg |
| Dimensions |
1.8 × 1.6 × 123 cm |
| System Compatibility |
3300 XL Proximity Transducer System |
| Condition |
Brand New |
| Origin |
USA |
| MOQ |
1 |
| HS Code |
8537101190 |
Functional Description
The 330101‑00‑09‑10‑02‑05 probe is engineered to deliver accurate displacement and vibration measurements across a wide operating range. Its compact design supports installation in tight or high‑density machinery layouts. The probe can be supplied with pre‑installed connector protectors to shield electrical connections from moisture, dust, and contaminants—an important feature for harsh industrial environments.
Connector protectors may also be ordered separately for field installations, especially when cables must be routed through narrow conduits or complex pathways. These accessories help maintain long‑term signal integrity and reduce maintenance requirements.
The probe is fully compatible with 3300 XL extension cables and Proximitor sensors, ensuring stable performance without requiring matched components or bench calibration.
Application Scenarios
FAQ
Q: Are connector protectors required for all installations They are recommended for environments with moisture, dust, or contaminants to ensure long‑term signal reliability.
Q: Is this probe compatible with older 3300 systems Yes. It is fully interchangeable with both XL and non‑XL 3300 5 mm and 8 mm components.
Q: Does the probe require calibration No. Calibration is performed at the Proximitor sensor level, not the probe.
