Description
Overview
The 330103-02-12-05-02-05 proximity probe is part of Bently Nevada’s 3300 XL 8 mm eddy‑current transducer family, engineered for precise shaft vibration and position measurement in high‑value rotating equipment. Designed for demanding industrial environments, this probe provides stable, linear output proportional to the probe‑to‑target gap, supporting both static and dynamic monitoring requirements.
Technical Specifications
| Parameter |
Value |
| Model Number |
330103-02-12-05-02-05 |
| Product Type |
8 mm Proximity Probe |
| Series |
3300 XL Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Thread Type |
M10 × 1 |
| Case Length |
120 mm minimum |
| Unthreaded Length |
20 mm |
| Cable Length |
0.5 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Type |
Static position + dynamic vibration |
| Compliance |
API 670 mechanical and performance requirements |
| Certifications |
CSA, ATEX, IECEx |
| Compatibility |
Fully interchangeable with 3300 XL and non‑XL 5 mm / 8 mm components |
| Application Use |
Fluid‑film bearing machines, Keyphasor, speed measurement |
| Dimensions |
28 × 26 × 6 cm |
| Weight |
1.48 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
High‑accuracy eddy‑current probe designed for critical rotating machinery.
-
M10 × 1 threaded housing supports secure installation in standard probe mounts.
-
20 mm unthreaded section improves mounting flexibility in deep or recessed housings.
-
0.5 m cable with ClickLoc connector ensures stable, vibration‑resistant electrical connections.
-
Fully API 670‑compliant linearity, accuracy, and temperature stability.
-
Certified for hazardous locations, suitable for oil & gas, power generation, and heavy industry.
-
Interchangeable components eliminate matched calibration requirements, reducing maintenance time.
-
Reliable performance for Keyphasor reference and speed measurement applications.
Application Scenarios
-
Turbine and compressor shaft vibration monitoring
-
Pump and motor displacement measurement
-
High‑temperature or hazardous‑area machinery installations
-
Predictive maintenance programs requiring precise displacement data
-
Keyphasor phase reference and rotational speed measurement
FAQ
Q: Does this probe require matched calibration with its extension cable? A: No. The 330103-02-12-05-02-05 is fully interchangeable with 3300 XL components without matched calibration.
Q: Is this probe suitable for hazardous environments? A: Yes. It carries CSA, ATEX, and IECEx approvals for classified industrial areas.
Q: What applications benefit from the 20 mm unthreaded section? A: It is ideal for installations requiring deeper insertion or where threaded engagement must be limited.
