Description
Overview
The 330103-01-06-05-02-05 proximity probe is part of Bently Nevada’s 3300 XL 8 mm transducer system, engineered for high‑accuracy shaft position and vibration monitoring. Designed for use in critical rotating machinery, the probe forms one component of a complete measurement chain that includes an extension cable and a Proximitor sensor.
Technical Specifications
| Parameter |
Value |
| Model Number |
330103-01-06-05-02-05 |
| Product Type |
8 mm Proximity Probe |
| Series |
3300 XL Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Probe Tip Diameter |
8 mm |
| Thread Type |
3/8‑24 UNF |
| Unthreaded Length |
0 mm |
| Case Length |
1.3 in |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Measurement Capability |
Static position + dynamic vibration |
| Compliance |
API 670 mechanical and performance requirements |
| Compatibility |
Fully interchangeable with 3300 XL and non‑XL 5 mm / 8 mm components |
| Dimensions |
1.8 × 1.6 × 123 cm |
| Weight |
0.06 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
High‑precision eddy‑current sensing for displacement and vibration monitoring.
-
Produces a voltage output proportional to the probe‑to‑target distance.
-
Suitable for fluid‑film bearing machines, Keyphasor reference, and speed measurement.
-
Fully interchangeable components eliminate the need for matched calibration.
-
Complies with API 670 requirements for linearity, accuracy, and temperature stability.
-
Lightweight, compact design supports easy installation in confined spaces.
-
ClickLoc connector ensures secure, vibration‑resistant electrical connections.
Application Scenarios
-
Turbine and compressor shaft vibration monitoring
-
Pump and motor displacement measurement
-
Keyphasor phase reference installations
-
Machinery protection systems requiring API‑compliant sensors
-
Retrofit projects using legacy 3300 series mounting patterns
FAQ
Q: Is this probe compatible with older 3300 series components? A: Yes. The 330103-01-06-05-02-05 is fully interchangeable with non‑XL 5 mm and 8 mm probes and extension cables.
Q: Does the probe require matched calibration with its extension cable? A: No. All 3300 XL components are designed for interchangeability without individual calibration.
Q: What applications benefit most from this 8 mm probe? A: It is ideal for fluid‑film bearing machinery where both static and dynamic measurements are required.
