Description
Overview
The 330103-00-07-10-01-05 proximity probe is part of Bently Nevada’s 3300 XL 8 mm transducer family, designed for accurate shaft vibration and displacement measurement in rotating equipment. Its compact, unarmored construction and M10 × 1 threaded body make it suitable for installations where mounting space is limited but high‑quality eddy‑current sensing is required.
Technical Specifications
| Parameter |
Value |
| Model Number |
330103-00-07-10-01-05 |
| Product Type |
8 mm Proximity Probe |
| Series |
3300 XL Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Probe Tip Diameter |
8 mm |
| Thread Type |
M10 × 1 |
| Minimum Case Length |
70 mm |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc with protector |
| Certifications |
CSA, ATEX, IECEx |
| Mounting Pattern |
Standard 4‑hole pattern |
| Dimensions |
28 × 26 × 6 cm |
| Weight |
1.48 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
High‑precision eddy‑current probe for shaft vibration and position monitoring.
-
Fully compatible with 3300 XL drivers and extension cables.
-
Backward‑compatible with non‑XL 3300 components; system performance defaults to non‑XL when mixed.
-
Unarmored design suitable for standard industrial environments without extreme mechanical abuse.
-
International hazardous‑area approvals for global deployment.
-
Compact threaded body simplifies installation in restricted mounting locations.
-
Improved signal integrity and stable performance across a wide operating range.
Application Scenarios
-
Turbine shaft vibration monitoring
-
Compressor and pump displacement measurement
-
Gearbox and motor bearing condition assessment
-
Machinery protection systems requiring certified 8 mm probes
-
Retrofit projects using legacy 3300 mounting patterns
FAQ
Q: Can this probe be used with older 3300 series components? A: Yes. The 330103-00-07-10-01-05 is backward‑compatible, though mixed systems operate at non‑XL performance levels.
Q: Is the probe suitable for hazardous locations? A: It carries CSA, ATEX, and IECEx certifications for classified industrial environments.
Q: What installation advantages does the unarmored design offer? A: It provides flexibility and easier routing in applications where armored cable protection is not required.
