Description
Overview
The 330101-00-40-20-12-05 proximity probe is part of Bently Nevada’s 3300 XL 8 mm eddy‑current transducer system, engineered for high‑accuracy shaft vibration and position monitoring in critical rotating machinery. Designed to meet API 670 (4th Edition) requirements, the probe delivers stable linearity, mechanical robustness, and temperature‑resilient performance suitable for demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
330101-00-40-20-12-05 |
| Product Type |
8 mm Proximity Probe |
| Series |
3300 XL Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Thread Type |
3/8‑24 UNF |
| Case Length |
2.0 m |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Cable Technology |
FluidLoc oil‑blocking cable |
| Operating Temperature |
–51 °C to +177 °C |
| Certifications |
CSA, ATEX, IECEx |
| Compatibility |
3300 XL and legacy 3300 5 mm / 8 mm systems |
| Dimensions |
1.8 × 1.6 × 123 cm |
| Weight |
0.06 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
High‑precision eddy‑current probe for displacement and vibration monitoring.
-
Fully API 670‑compliant mechanical and performance characteristics.
-
Interchangeable with 3300 XL probes, extension cables, and Proximitor sensors without calibration.
-
Backward‑compatible with earlier 3300 series systems for seamless retrofit integration.
-
FluidLoc cable prevents oil migration and enhances long‑term signal reliability.
-
Suitable for hazardous‑area installations with CSA, ATEX, and IECEx approvals.
-
Available in armored and unarmored versions to support diverse installation environments.
Application Scenarios
-
Turbine and compressor shaft vibration monitoring
-
Pump and motor displacement measurement
-
Machinery protection systems requiring API‑compliant sensors
-
High‑temperature or hazardous industrial environments
-
Retrofit projects using legacy 3300 series mounting patterns
FAQ
Q: Is this probe compatible with older 3300 series components? A: Yes. The 330101-00-40-20-12-05 is fully backward‑compatible with non‑XL 5 mm and 8 mm probes and extension cables.
Q: Does the probe require matched calibration? A: No. All 3300 XL components are designed for full interchangeability without individual calibration.
Q: What environments benefit from the FluidLoc cable? A: Applications where oil ingress or contamination could compromise signal integrity.
