Description
Overview
The 330101-00-13-10-12-CN proximity probe is part of Bently Nevada’s 3300 XL 8 mm transducer family, engineered for precise shaft vibration and position measurement in rotating machinery. Designed for long‑term reliability, the probe delivers stable eddy‑current sensing performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
330101-00-13-10-12-CN |
| Product Type |
8 mm Proximity Probe |
| Series |
3300 XL Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Thread Type |
3/8‑24 UNF |
| Unthreaded Length |
0.0 in |
| Case Length |
1.3 in |
| Cable Length |
1.0 m |
| Connector Type |
Miniature coaxial ClickLoc |
| Cable Type |
FluidLoc oil‑blocking cable |
| Mounting Pattern |
Standard 4‑hole pattern |
| Compatibility |
3300 XL and non‑XL 5 mm / 8 mm components |
| Dimensions |
1.8 × 1.6 × 123 cm |
| Weight |
0.06 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
High‑accuracy eddy‑current probe for shaft displacement and vibration monitoring.
-
3/8‑24 UNF threaded body supports secure installation in standard probe housings.
-
FluidLoc cable technology prevents oil migration and enhances long‑term signal integrity.
-
ClickLoc connector ensures reliable, vibration‑resistant electrical connections.
-
Fully interchangeable with legacy 3300 series probes without matched calibration.
-
Lightweight design simplifies installation while maintaining mechanical robustness.
-
Complies with minimum bend radius requirements for flexible routing in tight spaces.
Application Scenarios
-
Turbine and compressor shaft vibration monitoring
-
Pump and motor displacement measurement
-
Gearbox and bearing condition monitoring
-
Machinery protection systems using 3300 XL architecture
-
Retrofit applications requiring compatibility with older 3300 series probes
FAQ
Q: Can this probe be used with older 3300 series Proximitor sensors? A: Yes. The 330101-00-13-10-12-CN is fully backward‑compatible with non‑XL 5 mm and 8 mm components.
Q: What advantage does the FluidLoc cable provide? A: It prevents oil intrusion along the cable, improving long‑term measurement stability.
Q: Does the probe require matched calibration with its extension cable? A: No. All 3300 XL components are designed for full interchangeability.
