Description
Overview
The 21504-00-16-10-02 reverse‑mount proximity probe is part of Bently Nevada’s 3300 XL 8 mm sensing platform, engineered for accurate casing vibration and displacement monitoring on rotating machinery. Its compact, unthreaded design supports installations where traditional threaded probes cannot be used, offering flexibility for OEM and retrofit applications.
Technical Specifications
| Parameter |
Value |
| Model Number |
21504-00-16-10-02 |
| Product Type |
8 mm Reverse Mount Probe |
| Series |
3300 XL / 7200 Proximity Transducer System |
| Manufacturer |
Bently Nevada |
| Condition |
Brand New |
| Probe Tip Diameter |
8 mm |
| Case Length |
0.8 in (approx. 20 mm) |
| Cable Length |
1.0 m |
| Probe Style |
Unthreaded reverse‑mount design |
| Operating Use |
Casing vibration and shaft displacement monitoring |
| Dimensions |
1.8 × 1.6 × 123 cm |
| Weight |
0.06 kg |
| Origin |
USA |
| HS Code |
8537101190 |
| Availability |
In Stock |
| MOQ |
1 |
Key Features
-
Reverse‑mount configuration suitable for limited‑space installations and specialized mounting brackets.
-
8 mm eddy‑current sensing element optimized for casing vibration and displacement measurement.
-
Designed for compatibility with 3300 XL and 7200 series proximity transducer systems.
-
Robust construction supports operation in high‑temperature and contamination‑prone environments.
-
Provides stable, repeatable vibration data for machinery protection and predictive maintenance.
-
Ideal for applications requiring early detection of mechanical degradation.
Application Scenarios
-
Turbine and compressor casing vibration monitoring
-
Pumps, motors, and gearboxes with reverse‑mount probe housings
-
Machinery protection systems requiring compact, non‑threaded probes
-
Industrial environments with thermal cycling or airborne contaminants
FAQ
Q: What is the advantage of the reverse‑mount design? A: It allows installation from behind the mounting surface, useful when front‑side access is restricted or when OEM housings require unthreaded probes.
Q: Is this probe compatible with standard 3300 XL Proximitor sensors? A: Yes. The 21504-00-16-10-02 integrates seamlessly with 3300 XL drivers and extension cables.
Q: Can this probe be used in harsh environments? A: Its construction supports operation in high‑temperature and contamination‑exposed areas typical of heavy industrial machinery.
