Description
Bently Nevada 3300/45 Dual Differential Expansion Monitor
TheBently Nevada 3300/45-02-02-03-00(3300/45Dual Differential Expansion Monitor) serves as the primary3300/45instrument utilized to execute rotor-to-casing axial differential expansion measurement across Bently Nevada 3300 TSI platforms. Configured for rotor dynamics signal conversion, the module processes eddy-current proximity inputs with cross-talk suppression and channel-separated signal conditioning.
Suffix Breakdown & Model Matrix
-
3300/45: Dual Differential Expansion Monitor platform
-
-02 (A): Full-scale range 0 to 10 mm
-
-02 (B): 35 mm proximity transducer input configuration
-
-03 (C): Quad epoxy-sealed relay output module
-
-00 (D): Standard configuration without agency approval marking
HardwareSpecifications
| Parameter |
Specification |
| ModelBrand |
Bently Nevada 3300/45-02-02-03-00 |
| Origin |
USA |
| Weight |
1 kg |
| Dimensions |
Rack slot compatible (not specified) |
| OperatingTemp |
0 degC to +65 degC |
| Measurement Range |
0 to 10 mm |
| Transducer Input |
35 mm proximity probe system |
| Output Signal |
4-20 mA analog outputs |
| Relay Configuration |
Quad relay epoxy sealed |
| Frequency Response |
0 to 10 kHz |
Eddy-Current Probe Scaling and Cross-Talk Suppression Behavior
The module applies eddy-current transducer scaling for long-range axial displacement measurement using 35 mm probe systems. Input conditioning maintains stable gap voltage validation referenced to negative bias excitation architecture typical of Bently Nevada proximity systems. Internal channel separation logic reduces cross-talk between parallel monitoring channels, preserving signal integrity during transient rotor dynamics conditions and thermal expansion transitions.
FrequentlyAskedQuestions
Q: Can the 3300/45 accept mixed probe sizes on different channels?
A: No. Both channels must use the configured 35 mm transducer scaling to maintain linear displacement conversion.
Q: What happens if relay outputs are wired without separation?
A: Shared routing between Alert and Danger relay paths can introduce feedback coupling and invalid alarm state interpretation.
Q: Is firmware or logic upgrade required for transducer recalibration?
A: No firmware update is required; calibration is handled through hardware scaling and front panel configuration.
FieldInstallationGuidelines
-
Ensure rack backplane is de-energized before module insertion or removal
-
Verify correct mating of 35 mm proximity probe input connectors before power application
-
Maintain shield termination at designated system ground point to reduce noise coupling
-
Route transducer cables separately from high voltage switching lines to avoid induced interference
-
Confirm relay wiring segregation between alarm tiers to prevent loop interaction
-
Avoid mechanical stress on coaxial diagnostic outputs during installation and maintenance
