The Bently Nevada 3300/16-12-01-00-00 is a dual-channel vibration monitoring module designed for the 3300 Series machinery protection system. This unit provides continuous, reliable monitoring of radial shaft vibration, specifically configured for XY channel applications. It is engineered to protect critical rotating assets such as industrial turbines, large compressors, and centrifugal pumps by detecting vibration anomalies and triggering protective responses.
Features
- Dual-channel input architecture optimized for proximity probe (Proximitor) sensor arrays.
- Integrated signal processing for real-time radial shaft vibration measurement.
- Dedicated alarm logic with Alert and Danger setpoint comparison.
- Front-panel LED status indicators for rapid diagnostics (OK, Bypass, Alert, and Danger).
- Proportional 4-20 mA outputs for integration with external control systems or data acquisition platforms.
- Standard relay outputs for machine trip and alarm signaling.
Technical Specifications
| Model |
3300/16-12-01-00-00 |
| Brand |
Bently Nevada |
| Series |
3300 |
| Inputs |
2 x Proximity Probe Channels |
| Outputs |
4-20 mA, Dynamic Signal, Relay (Alert/Danger) |
| Operating Temperature |
-30 degC to +65 degC |
| Power Consumption |
6 W (typical) |
Installation Guidelines
- Ensure the 3300 Series rack is de-energized before inserting or removing the module to prevent electrical damage.
- Verify that all proximity probes are correctly calibrated and connected to the module's input terminals.
- Maintain proper grounding practices for the 3300 rack to minimize EMI/RFI interference on sensitive vibration signals.
- Ensure adequate airflow within the cabinet to maintain operating temperatures within the specified -30 degC to +65 degC range.
- Use shielded cabling for all I/O connections to maintain signal integrity in high-noise industrial environments.
FAQ
What is the primary function of the 3300/16-12-01-00-00?
This module is a dual-channel vibration monitor used to measure and analyze radial shaft vibration in rotating machinery, providing essential alarm and trip functionality for protection systems.
Is this module compatible with standard proximity sensors?
Yes, the 00 configuration for the transducer input option is specifically designed for use with standard Bently Nevada Proximitor sensors.
What do the status LEDs on the front panel indicate?
The LEDs provide visual confirmation of the module's health and the machine's status, including OK (sensor/module health), Bypass, Alert, and Danger alarm states.
