The Bently Nevada 3300/10-01-01-00-00 is a rack-integrated Power Supply Module engineered to provide stable, regulated DC voltage to all monitoring modules within the 3300 series system. As a critical component for machinery protection, this unit ensures the continuous and reliable operation of vibration, thrust, eccentricity, and tachometer monitoring instrumentation by delivering clean power across the backplane.
Features
- Provides regulated DC output to support full rack capacity.
- Integrated rack-wide OK status monitoring to signal power health.
- Designed for standard 115/230 VAC input configurations.
- Robust construction for industrial rack-mount environments.
- Ensures consistent signal integrity for sensitive vibration monitoring sensors.
Applications
This power supply module is fundamental to the 3300 Monitoring System, commonly used in critical rotating machinery protection applications such as steam turbines, gas turbines, compressors, and large motors. It is designed for use in environments where consistent power delivery is required to maintain accurate monitoring of machine health parameters.
Technical Specifications
| Model |
3300/10-01-01-00-00 |
| Brand |
Bently Nevada |
| Series |
3300 |
| Input Voltage |
115/230 VAC |
| Operating Temperature |
0 to 60 degC |
| Rack Compatibility |
3300 System Rack |
| Output |
Regulated DC for rack modules |
Installation Guidelines
- Ensure the 3300 rack is powered down before inserting or removing the module to prevent electrical damage.
- Verify that the AC input voltage matches the module configuration before applying power.
- Slide the module into the designated rack slot, ensuring proper alignment with the backplane connectors.
- Secure the front panel screws to ensure a solid ground connection and physical stability.
- Maintain adequate ventilation around the rack to prevent internal component overheating during operation.
- Handle with standard ESD precautions to protect internal circuitry.
FAQ
Does this module support dual power inputs?
The 3300/10 module is designed for standard AC input. Please verify your specific site power requirements against the 01-01 suffix configuration to ensure compatibility with your existing rack setup.
Is this module compatible with other Bently Nevada systems?
This module is specifically designed for the 3300 System. It is not interchangeable with 3500 series or other Bently Nevada rack architectures.
What does the OK status relay indicate?
The OK relay provides a diagnostic signal indicating that the internal DC power rails are within specified operating limits. If the relay trips, it signifies a failure or loss of power regulation within the rack.
