Bently Nevada 1900/65 167707-01 General Purpose Equipment Monitor

The Bently Nevada 1900/65 167707-01, also cataloged as the 1900/65 General Purpose Equipment Monitor, operates as a dedicated hardware component for vibration and speed signal monitoring within industrial machinery protection and condition monitoring systems.

Hardware Specifications

Parameter	Specification
Model	1900/65 167707-01
Brand	Bently Nevada
Product Type	General Purpose Equipment Monitor
Origin	USA
Weight	1.32 kg
Dimensions	19.8 x 15 x 11 cm (shipping size)
Operating Temp	Not specified
Power Consumption	Not specified
Vibration Variables	Accuracy: +/-1% of full-scale range
Speed Variables	Accuracy: +/-0.5 RPM + 0.015% of reading
Speed Measurement Range	100 - 100,000 rpm
Speed Measurement Channels	Up to 4 speed measurements
Voltage Mode Input	3-wire voltage mode, 10 kOhm input impedance
Bias Filter	0.09 Hz, 1-pole low-pass filter
OK Filter	2.4 kHz, 1-pole low-pass filter
Bias Voltage	-24 V

Eddy-Current Probe Scaling and Rotor Dynamics Signal Processing

The 1900/65 monitor processes machinery condition signals associated with vibration and rotational speed measurements. The vibration input architecture supports voltage-based monitoring channels with defined filtering characteristics for dynamic machinery signals. The monitor can be integrated with eddy-current probe measurement systems where probe scaling and gap voltage validation are required for shaft displacement monitoring.

The proximity measurement interface requires verification of probe operating conditions, including gap voltage targets commonly referenced around -10 VDC for eddy-current probe systems. Proper probe scaling configuration allows accurate interpretation of shaft movement signals related to rotor dynamics, including vibration amplitude and rotational behavior.

The input filtering design provides separation between low-frequency bias components and higher-frequency vibration signals, supporting measurement stability in rotating equipment monitoring applications.

Frequently Asked Questions

Q: How many speed signals can the 1900/65 167707-01 monitor simultaneously?
A: The monitor supports up to 4 speed measurements. The specified speed measurement range is 100 - 100,000 rpm.

Q: What type of vibration input signal does the 1900/65 167707-01 support?
A: The monitor supports 3-wire voltage mode inputs with a 10 kOhm input impedance. The vibration measurement accuracy is specified as +/-1% of full-scale range.

Q: Does the 1900/65 provide probe gap voltage monitoring?
A: The monitor supports signal processing associated with proximity measurement systems. Probe installation requires correct gap voltage validation and sensor configuration according to the connected eddy-current probe specifications.

Field Installation Guidelines

• Install the monitor in an enclosure or rack system that provides mechanical protection and appropriate environmental control.
• Use shielded instrumentation wiring for vibration and speed signal connections to reduce electrical interference.
• Connect cable shields according to the site grounding practice to minimize signal noise and measurement instability.
• Separate low-level vibration signal wiring from high-current power cables and switching circuits.
• Verify sensor wiring polarity, excitation requirements, and signal scaling before commissioning.
• Confirm proximity probe installation conditions, including mechanical clearance and electrical signal response, before enabling machinery monitoring functions.
• Ensure all terminal connections are secured and inspected before system startup.

Specifications

• Brand: Bently Nevada

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
