Bently Nevada 136386-01 Blank Filler Panel
The Bently Nevada 136386-01, also cataloged as the 136386-01 Blank Filler Panel, operates as a passive mechanical rack element for slot occupancy within Bently Nevada 3500 series chassis architectures.
Configured for unused module bay sealing in 3500 rack assemblies, the Bently Nevada 136386-01 (136386-01 filler panel) provides physical slot coverage and airflow continuity without electrical participation in the monitoring backplane.
Hardware Specifications
| Parameter |
Specification |
| Model |
136386-01 |
| Brand |
Bently Nevada |
| Weight |
0.2 kg |
| Dimensions |
140 mm × 80 mm × 30 mm |
| Operating Temp |
–40 deg C to +70 deg C |
| Power Consumption |
None (passive component) |
| Function |
Non-functional rack slot filler |
| Material |
Aluminum alloy, conformal coated |
| Environmental Rating |
Rack-level dust and airflow protection |
| Storage Temperature |
–40 deg C to +85 deg C |
Rack Airflow Integrity and Cross-Slot Mechanical Stabilization Behavior
The filler panel maintains chassis airflow channel uniformity by sealing unused slot apertures in the 3500 rack backplane structure.
This mechanical sealing reduces localized turbulence within the rack ventilation path, preserving designed cooling flow distribution across active monitoring modules.
The aluminum alloy structure provides uniform mechanical load distribution across the rack frame, preventing structural imbalance caused by partially populated module bays.
Conformal coating ensures surface isolation from airborne particulates and moisture accumulation, maintaining consistent rack environmental impedance over long operational cycles.
No electrical interface is present; the component does not participate in backplane communication, signal routing, or grounding reference paths.
Frequently Asked Questions (FAQ)
Q: Does the 136386-01 connect to the 3500 backplane electrically?
A: No. The module is mechanically passive and has no electrical or data interface with the backplane.
Q: Can the filler panel be omitted in partially populated racks?
A: It is not recommended. Missing panels may alter airflow distribution and reduce thermal stability across installed modules.
Q: Does the coating affect rack grounding continuity?
A: No. The filler panel does not participate in grounding paths and serves only as a mechanical cover element.
Field Installation Guidelines
Insert the filler panel into any unused 3500 rack slot until full mechanical engagement is achieved. Ensure alignment with adjacent module guides to maintain uniform front-panel surface continuity.
Do not leave open slots exposed during operation, as airflow imbalance and dust ingress may occur within the rack enclosure. Maintain consistent distribution of filler panels across partially populated racks.
Avoid forcing insertion; improper alignment may damage rack guide rails or adjacent module housings. Confirm that adjacent modules are fully seated before installation.
Routine inspection is recommended to ensure filler panels remain secured and flush with the rack front plane.
