Description
Bently Nevada 131178-01 Industrial Communication Cable
The Bently Nevada 131178-01, also cataloged as the 131178-01 Industrial Communication Cable, operates as a dedicated hardware component for data transfer and configuration between Rack Interface Modules (RIM), Transient Data Interfaces (TDI), and host PCs within the 3500 Series Machinery Protection System.
Suffix Breakdown & Model Matrix
The supplied documentation identifies 131178-01 as a fixed-length, shielded DB9 female-to-female cable. No additional suffix options or variant matrix information is specified.
Hardware Specifications
| Parameter |
Specification |
| Model |
131178-01 |
| Brand |
Bently Nevada |
| Origin |
USA |
| Weight |
0.2 kg |
| Dimensions |
3 m length |
| Operating Temp |
Industrial-grade (typical control room range) |
| Product Type |
Industrial Communication Cable |
| Connector Type |
DB9 Female to DB9 Female |
| Shielding |
EMI/RFI industrial-grade |
| Construction |
Heavy-duty jacket, gold-plated pins |
| Compatibility |
Bently Nevada 3500 Series RIM & TDI |
| Protocol Support |
Proprietary Bently Nevada configuration & data retrieval |
Industrial Communication Integrity
The cable maintains signal integrity across the 3-meter connection between RIM and TDI modules. EMI/RFI shielding reduces induced noise in electrically harsh industrial environments, while gold-plated DB9 contacts ensure low contact resistance over repeated insertions. The proprietary pinout enforces handshake consistency and prevents miscommunication errors when interfacing with System 1™ or other host software. Compatibility includes both legacy 3500/20 RIM and 3500/22M TDI modules, supporting deterministic waveform data transfers.
Frequently Asked Questions (FAQ)
Q: Can the 131178-01 cable be used with third-party RS232 devices?
A: The cable uses a proprietary Bently Nevada pinout; standard RS232 devices may not communicate correctly without a compatible adapter.
Q: Does the cable provide shielding against industrial noise?
A: Yes. The cable includes EMI/RFI shielding suitable for industrial environments to ensure stable data transfer.
Q: Is this cable suitable for outdoor or harsh environment use?
A: The cable is rated for industrial control room use. For exposure beyond standard industrial environments, additional protective conduit is recommended.
Field Installation Guidelines
-
Route the cable away from high-voltage conductors and motor leads to minimize inductive coupling.
-
Ensure both DB9 connectors are securely seated in their respective RIM or TDI sockets; verify pin alignment before powering the system.
-
Use cable ties or trays to support the cable along its full length to prevent mechanical stress or bending beyond manufacturer recommendations.
-
Maintain shielding continuity by connecting the cable shields to system ground at one end.
-
Avoid sharp bends or kinks in the cable to prevent degradation of signal integrity over time.
