Description
Product Overview
The 125800-02 Enhanced Keyphasor Module from Bently Nevada delivers precise phase reference signals for rotating machinery. Designed for the 3500 system, it ensures accurate timing and synchronization in critical control applications.
This module measures 2.5 × 11.2 × 24.2 cm and weighs 0.48 kg, offering a compact form factor for space-constrained installations. Its internal terminations simplify wiring and reduce maintenance time, improving overall system reliability.
The 125800-02 operates on a flexible input voltage range of 12VDC to 28VDC and consumes only 2 watts of power. Its wide operating temperature range from -40°C to +85°C ensures consistent performance in extreme industrial environments.
Built with robust materials and optimized for energy efficiency, the 125800-02 supports Ethernet router communication and integrates seamlessly with Bently Nevada’s monitoring infrastructure.
Technical Specifications
| Parameter |
Specification |
| Model Number |
125800-02 |
| Manufacturer |
Bently Nevada |
| Product Series |
3500 System |
| Module Type |
Enhanced Keyphasor Module |
| Weight |
0.48 kg |
| Dimensions |
2.5 × 11.2 × 24.2 cm |
| Input Voltage |
12VDC to 28VDC |
| Power Consumption |
2 watts |
| Operating Temp. |
-40°C to +85°C |
| Terminations |
Internal |
| Interfaces |
Ethernet Router |
| System Compatibility |
TSI |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Discontinued On |
Active |
Applications & Compatibility
The 125800-02 suits industries requiring precise phase tracking and synchronization, including turbines, compressors, and high-speed rotating equipment. It integrates with distributed control systems (DCS), programmable logic controllers (PLC), and condition monitoring platforms. Its compact design and flexible voltage support make it ideal for both new installations and system upgrades.
