Description

Bently Nevada 100767-01 3500 Series Control Module

Configured for dynamic pressure and vibration signal processing in the Bently Nevada 3500 Machinery Protection System, the Bently Nevada 100767-01 (100767-01 Control Module) provides direct physical and electrical execution for machinery condition data acquisition and monitoring functions.

Hardware Specifications

Parameter	Specification
Model	100767-01
Brand	Bently Nevada
Product Type	Control Module
Series	3500 Machinery Protection System
Origin	USA
Weight	Approx. 0.8 kg
Dimensions	88.9 mm W x 266.7 mm H x 165.1 mm D
Operating Temp	-40 deg C to +70 deg C
Application	Dynamic pressure and vibration monitoring
Input Signal Type	Compatible vibration and dynamic pressure sensor signals
Signal Processing	Signal conditioning, filtering, and scaling
Communication Interface	3500 Series internal system communication
Mounting Type	3500 rack installation
Storage Temperature	-40 deg C to +85 deg C
Humidity Range	5% to 95% non-condensing

Eddy-Current Measurement and Rotor Dynamics Processing

The Bently Nevada 100767-01 operates within the 3500 platform architecture for machinery monitoring signal handling. The module processes measurement data from compatible field sensors and supports vibration-related monitoring functions.

Bently Nevada monitoring systems typically apply eddy-current probe scaling methods for shaft displacement measurement. Signal conditioning evaluates probe response characteristics, while gap voltage validation can use -10 VDC target references for confirming probe operating conditions.

The module architecture supports rotor dynamics analysis by maintaining measurement consistency for rotating equipment monitoring. Signal processing methods include filtering and scaling functions to reduce measurement interference and support vibration data interpretation.

Frequently Asked Questions

Q: Is the 100767-01 designed for installation in a standalone configuration?
A: No. The module is designed as a rack-mounted component within the Bently Nevada 3500 Machinery Protection System architecture.

Q: What type of field signals can be connected to this module?
A: The module processes compatible vibration and dynamic pressure measurement signals from approved Bently Nevada sensor interfaces.

Q: Does the module require specific installation considerations for signal quality?
A: Yes. Field wiring should maintain proper shielding, grounding, and separation from high-voltage conductors to reduce electrical interference.

Field Installation Guidelines

• Install the module into an approved Bently Nevada 3500 rack slot according to system configuration requirements.
• Verify rack power availability and module seating before commissioning.
• Connect field sensor wiring with correct shielding and grounding practices.
• Separate low-level measurement signal cables from power and switching circuits.
• Confirm sensor wiring polarity and termination before applying system power.
• Perform system diagnostics through the 3500 monitoring platform after installation.

Specifications

• Brand: Bently Nevada

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
