Allen Bradley 1769-RTBN10 Removable Terminal Block
Configured for field wiring termination in industrial control panels, the Allen Bradley 1769-RTBN10, also cataloged as the 1769-RTBN10 Removable Terminal Block, provides direct physical/electrical execution.
Hardware Specifications
Parameter
Specification
Model
1769-RTBN10
Brand
Allen Bradley
Origin
Standard Industrial Origin
Weight
0.56 lbs (0.26 kg)
Dimensions
Standard CompactLogix I/O footprint
Operating Temp
Industrial standard rating (0 deg C to 60 deg C)
Power Consumption
Passive pass-through component (0 W)
Core Performance
10-pin NEMA connector, 22–14 AWG wire range
Profinet / EtherNet/IP Deterministic Networks
Engineers integrate the Allen Bradley 1769-RTBN10 directly within CompactLogix I/O architectures to secure deterministic network execution at the physical field level. By maintaining robust backplane bus communication velocity linkages, this terminal block ensures that discrete field signals interface seamlessly without signal degradation. Furthermore, its mechanical locking mechanism and screw-clamp retention profile prevent terminal loosening caused by continuous industrial vibration across high-density I/O node deployments.
Frequently Asked Questions
Q: What wire gauge range does the 1769-RTBN10 support for field wiring?
A: The unit accommodates solid or stranded wire sizes ranging from 22 AWG to 14 AWG.
Q: Is the 1769-RTBN10 rated for hot-swapping applications?
A: Users must remove field power before inserting or extracting the terminal block from the 1769 CompactLogix I/O module to prevent electrical arcing and backplane damage.
Field Installation Guidelines
When installing the 1769-RTBN10, first ensure that all relevant control power sources are powered down to avoid equipment damage or electrical shock. Align the snap-on module connection carefully with the corresponding 1769 CompactLogix I/O module housing. Press the terminal block firmly into place until the locking mechanism engages completely. Secure each individual conductor within the screw-clamp interface using the recommended torque specifications to maintain optimal electrical conductivity and mechanical stability under continuous operational vibration.
