Allen Bradley 1756-IF16 ControlLogix 16 Point Analog Input Module

BrandAllen-Bradley
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Allen Bradley 1756-IF16 ControlLogix 16 Point Analog Input Module

BrandAllen-Bradley
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Product Overview The Allen-Bradley 1756-IF16 Analog Input Module is a high-performance I/O solution within the ControlLogix® architecture, designed to handle... Read more

SKU: 1756-IF16
Country of origin: USA

100% Original and Authentic

Do you need a large stock? Contact us.

100% Brand New，Ready to ship

Do you need a large stock? Contact us.

Support Refund,7X24h Service

Support Refund,7X24h Service , Contact us.

Call us: +86 135 995 07613

Available on working days between 9:00 am to 6:00 pm

Email us: sales2@industriaxplc.com

Available 24/7 for inquiries and support

Description

Product Overview

The Allen-Bradley 1756-IF16 Analog Input Module is a high-performance I/O solution within the ControlLogix® architecture, designed to handle complex analog signal acquisition across industrial automation systems. It supports 16 single-ended, 8 differential, or 4 high-speed differential inputs, offering flexible configuration for voltage and current-based sensors.

Technical Specifications

Attribute	Detail
Manufacturer	Allen-Bradley
Part Number	1756-IF16/A
Product Series	ControlLogix
Input Channels	16 single-ended / 8 differential / 4 high-speed differential
Input Range	±10V, 0–10V, 0–5V, 0–20 mA
Resolution	Up to 320 μV/count or 0.32 μA/count
Current Draw @ 5.1V	150 mA
Current Draw @ 24V	65 mA
Power Consumption	2.33 W
Power Dissipation	Voltage: 2.33 W / Current: 4.00 W
Thermal Dissipation	Voltage: 7.93 BTU/hr / Current: 13.65 BTU/hr
Input Impedance	Voltage: ≥10 MΩ / Current: 249 Ω
Overvoltage Protection	Voltage: 30V DC / Current: 8V DC
Normal Mode Noise Rejection	>80 dB @ 50/60 Hz
Common Mode Noise Rejection	>100 dB @ 50/60 Hz

Applications & Compatibility

The 1756-IF16 module is ideal for process control, data acquisition, and precision monitoring in industries ranging from manufacturing to energy. It integrates seamlessly with ControlLogix chassis and controllers, supporting scalable architectures and distributed control systems.
