Description
Overview
The ABB TER800 Bus Terminator ensures reliable communication for HN800 and CW800 bus systems. Engineers install one terminator at each end of the bus to maintain signal integrity and stable performance in demanding automation environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
TER800 |
| Module Type |
Bus Terminator |
| Manufacturer |
ABB |
| Part Number |
TER800 |
| Product Catalog |
Symphony Plus |
| Voltage |
24 VDC |
| Current |
0.2 A |
| Dimensions |
9.5 × 22.9 × 15.2 mm |
| Weight |
0.136 kg |
| System |
DCS |
| Product Origin |
Sweden |
| Lead Time |
In Stock |
| Status |
Active |
Functional Description
The ABB TER800 provides termination for HN800 and CW800 buses, ensuring proper signal transmission. Engineers benefit from its compact design, which simplifies installation in space-constrained environments. The module supports 24V DC operation with 0.2A current consumption, offering efficient and reliable performance.
Design and Build
The ABB TER800 measures 9.5x22.9x15.2mm and weighs 0.136kg, making it lightweight yet durable. Its construction meets strict ABB quality standards, ensuring long-term reliability. Each unit undergoes testing before shipment, guaranteeing consistent performance.
Applications and Compatibility
The ABB TER800 Bus Terminator integrates seamlessly with Symphony Plus systems. Engineers deploy it in industrial automation projects requiring stable bus communication, including power generation, manufacturing, and process industries. One terminator must be installed at each end of the bus to ensure proper operation.
Key Benefits
-
Compact 0.136kg design supports space-limited installations.
-
Ensures reliable signal integrity for HN800 and CW800 buses.
-
24V DC operation with 0.2A current consumption.
-
Tested and certified for consistent ABB quality standards.
