The ABB TBU810 Terminal Base Unit provides a secure housing for modules with integrated power and communication ports. Engineers rely on its compact design, mechanical locking devices, and redundant configuration capability to ensure reliable operation in demanding automation environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
TBU810 |
| Module Type |
Terminal Base Unit |
| Manufacturer |
ABB |
| Condition |
Brand New |
| Product Catalog |
Symphony Plus |
| Voltage |
24 VDC |
| Current |
4–20 mA |
| Dimensions |
124 × 186 × 30 mm |
| Weight |
0.7 kg |
| System |
DCS |
| Product Origin |
Sweden |
| MOQ |
1 |
| Lead Time |
In Stock |
| Status |
Active |
Functional Description
The ABB TBU810 houses modules while providing power terminals, Profibus connectors, serial interface ports, redundant communication ports, and relay outputs. Engineers benefit from its ability to mount on standard DIN rails with a mechanical latch that locks securely in place. Two mechanical locking devices ensure modules remain firmly attached during operation.
Design and Build
The ABB TBU810 measures 124x186x30mm and weighs 0.7kg, offering a compact yet durable build. Its design supports redundant configurations by mounting two units side by side, creating a communication path for paired modules. The latch mechanism simplifies installation and removal using a screwdriver.
Applications and Compatibility
The ABB TBU810 Terminal Base Unit integrates seamlessly with Symphony Plus systems. Engineers deploy it in power generation, manufacturing, and process industries requiring reliable module housing and redundant communication paths. Its compatibility with Profibus and serial interfaces ensures flexible integration across diverse automation environments.
Key Benefits
-
Compact 0.7kg design supports space-constrained installations.
-
Provides power, Profibus, serial, and redundant communication ports.
-
Mechanical latch and locking devices ensure secure module placement.
-
Supports redundant configurations for uninterrupted system operation.
