ABB SPIET800 INFI-Net to Ethernet Transfer Module
Configured for INFI-Net to Ethernet data transfer within ABB Symphony Plus and Harmony systems, the ABB SPIET800 (SPIET800 INFI-Net to Ethernet Transfer Module) provides communication between the INFI-Net control network and Ethernet-based host systems. It supports data exchange with engineering, operator, OPC, and supervisory software environments.
Hardware Specifications
Parameter
Specification
Model
SPIET800
Brand
ABB
Product Type
INFI-Net to Ethernet Transfer Module
Product Series
ABB Ability Symphony Plus / Harmony
Primary Function
INFI-Net to Ethernet communication transfer
INFI-Net Interface
INFI-Net network connection
Ethernet Interface
Ethernet communication, TCP/IP
Supported Software
S+ Engineering, S+ Operations (HSI), Harmony OPC Server, 800xA for Symphony Plus Harmony
Firmware
Version A_D or later recommended according to supplied information
Firmware Compatibility
Firmware updates should match the installed SPIET800 hardware and system release
Mounting
ABB DCS rack/chassis mounting
Operating Environment
Standard industrial process control environment
ABB Industrial Network Communication Characteristics
The SPIET800 performs protocol-level communication between the INFI-Net control network and Ethernet-connected host systems. Therefore, the module should be treated as a network interface component rather than a conventional discrete I/O module.
Ethernet communication uses TCP/IP-based connectivity for host-side data exchange. In addition, the module supports integration with S+ Engineering, S+ Operations (HSI), Harmony OPC Server, and 800xA for Symphony Plus Harmony.
For ABB control-system installations, firmware compatibility must be checked against the installed system release before replacement or upgrade. The supplied information identifies version A_D or later as the recommended firmware level for addressing legacy vulnerability patches.
The module does not provide sufficient supplied data to establish a specific backplane communication rate, Ethernet port speed, channel count, or power-load value. These parameters should therefore be verified against the applicable ABB hardware manual before system engineering.
Frequently Asked Questions
Q: Can the SPIET800 directly replace an existing module without checking firmware? A: No. The supplied data identifies firmware version A_D or later as recommended. The installed system release and module firmware compatibility should be verified before replacement.
Q: Does the SPIET800 provide Ethernet communication? A: Yes. The supplied specifications identify an Ethernet interface with TCP/IP support for communication with host-side systems.
Q: Does the supplied information define the module power consumption? A: No. A specific power-consumption value is not provided. The applicable ABB hardware documentation should be used to determine the actual rack or backplane load.
Field Installation Guidelines
Install the SPIET800 in the designated ABB DCS rack or chassis position.
Confirm that the rack configuration supports the installed module before energizing the system.
Connect the INFI-Net network interface according to the ABB system wiring documentation.
Connect the Ethernet interface using the approved network topology and cabling specified for the host system.
Keep Ethernet communication wiring separated from high-voltage power conductors and high-current switching circuits where practical.
Maintain appropriate cable shielding and grounding practices according to the ABB installation documentation and site electrical standards.
Verify Ethernet addressing, network parameters, and host-system configuration before placing the communication path into service.
Confirm the installed firmware revision before performing configuration or commissioning work.
Do not infer unsupported hot-swap capability, power consumption, environmental limits, or network performance values from the module designation alone.
After installation, verify INFI-Net communication and Ethernet host communication independently before returning the associated control system to normal operation.
