The ABB GJR2393100R1200 (88FT05C-E) is a specialized Remote-Bus Coupling Module designed for the ABB Procontrol P14 and System 800xA distributed control environments. This module serves as a critical interface, facilitating reliable communication and data exchange between local station buses and remote bus networks. It is engineered to maintain high-speed, deterministic data throughput required for complex industrial automation and safety-critical applications.
Features
- Designed for integration within the Procontrol P14 platform.
- Functions as a station modem and bus coupling module (88TK05 compatibility).
- High-speed communication interface for distributed control stations.
- Robust design suitable for demanding industrial environments.
- Supports seamless data exchange across remote bus architectures.
Applications
-
Thermal Power Plants: Distributed control systems for gas-fired power generation units.
-
Nuclear and Hydroelectric: Control network management for conventional islands and power generation infrastructure.
-
Metallurgy and Steel: Interface for blast furnaces, converters, and continuous casting equipment.
-
Petrochemical Industry: Distributed control for large-scale oil refining and ethylene production facilities.
Technical Specifications
| Model |
GJR2393100R1200 / 88FT05C-E |
| Manufacturer |
ABB |
| Platform |
Procontrol P14 |
| Power Supply |
24V DC +/- 20% |
| Power Consumption |
15W (typical) |
| Isolation |
1500V AC |
| Latency |
<100 microseconds |
| Operating Temperature |
-40 degC to +70 degC |
| Storage Temperature |
-40 degC to +85 degC |
| Humidity |
5-95% non-condensing |
Installation Guidelines
- Ensure the system power is completely disconnected before installing or removing the module to prevent electrical damage.
- Mount the module in a clean, dry, and well-ventilated cabinet to maintain the specified operating temperature range.
- Use shielded communication cables to minimize electromagnetic interference (EMI) in high-noise industrial environments.
- Verify that the module is securely seated in the rack backplane to ensure proper electrical contact.
- Follow standard ESD (Electrostatic Discharge) precautions when handling the module to protect internal circuitry.
FAQs
What is the primary function of the GJR2393100R1200?
This module acts as a data bridge, enabling communication between the local station bus and remote bus networks within the ABB Procontrol P14 system.
Is this module compatible with System 800xA?
Yes, it is designed for use within ABB Procontrol P14 and System 800xA distributed control system architectures.
What are the environmental limits for this module?
The module is rated for operation between -40 degC and +70 degC with a humidity range of 5-95% non-condensing.
