Description
The ABB HEDT300813R1 is a component module designed for the Procontic DP800 series control system. This unit, identified as a PC board assembly, is designated with the spare model reference ED1633. As a legacy component, it is currently discontinued by the manufacturer, making it a critical spare part for maintaining existing Procontic DP800 installations.
Features
- Designed specifically for integration within the ABB Procontic DP800 architecture.
- PC board assembly construction ensuring compatibility with legacy control hardware.
- Direct replacement for ED1633 designated assemblies.
- Engineered for industrial control environments requiring reliable signal processing or logic handling.
Applications
This module is intended for use in industrial automation systems utilizing the ABB Procontic DP800 platform. It is commonly employed in manufacturing, process control, and legacy infrastructure where the DP800 series remains in operation.
Technical Specifications
| Product Model |
HEDT300813R1 |
| Spare Model |
ED1633 |
| Manufacturer |
ABB |
| Product Type |
PC Board Assembly |
| Weight |
0.32 kg |
Installation Guidelines
- Ensure the control system is fully powered down before attempting to remove or install this module to prevent electrical damage.
- Handle the PC board assembly by the edges to avoid electrostatic discharge (ESD) damage to sensitive components.
- Verify that the module is correctly seated in the designated slot within the Procontic DP800 rack.
- Ensure the environment is free from excessive dust, moisture, and high-EMI sources to maintain operational integrity.
- Check for proper alignment of connector pins before applying pressure to seat the module.
FAQ
Is this module compatible with other ABB systems?
The HEDT300813R1 is specifically engineered for the Procontic DP800 series. It is not intended for use in other ABB product families such as the AC 800M or S800 I/O systems.
What does the ED1633 designation mean?
ED1633 is the internal spare model or revision reference for this specific PC board assembly. It is used to ensure the correct hardware version is utilized during maintenance or replacement procedures.
