Description

Overview

The PHARPSCH100000 is a robust and modular Power Supply Chassis from ABB’s Modular Power System III (MPS III), designed to deliver multiple DC voltages to Harmony rack components within the Symphony Enterprise Management and Control System. It supports both system and field power requirements, with flexible tray configurations and monitoring capabilities.

Key Features

• Modular Architecture

  • Supports one or two power supply trays

  • Easily expandable and customizable for project-specific needs

• Multi-Voltage Output

  • System Power: 5 VDC, +15 VDC, -15 VDC

  • Field Power: 24 VDC (actual 25.5 VDC), 48 VDC, 125 VDC

• Global Compatibility

  • Accepts a wide range of input voltages

  • Suitable for diverse power grid environments

• Integrated Monitoring

  • Includes DC bus monitor and status output connections

  • Supports system fan and cabinet temperature monitoring

• Rack-Mountable Design

  • Standard 19-inch rack compatibility

  • Compact footprint for space-efficient cabinet integration

Technical Specifications

Specifications

• Dimensions: 540 mm x 230 mm x 550 mm
• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
