Description

Overview

The PHARPS32200000 module is part of ABB’s Modular Power System III (MPS III), engineered to supply reliable and flexible power to Harmony rack modules and field-mounted devices. It supports a wide range of DC outputs and mixed AC/DC input feeds, making it ideal for industrial environments requiring high uptime, redundancy, and serviceability.

Key Features

• Multi-Voltage Output:

  • System Power: 5 VDC, +15 VDC, 24 VDC

  • Field Power: 24 VDC, 48 VDC, 125 VDC

• Flexible Input Options:

  • Accepts 120/240 VAC or 125 VDC feeds

  • Supports mixed AC/DC operation

• 2N Redundancy Support:

  • Dual feed (main/auxiliary) configurations

  • Automatic load sharing for increased MTBF

• Serviceability & Monitoring:

  • Local status indicators and disconnects

  • Online replacement capability

  • Monitors fan status, cabinet temperature, and power outputs

• Smart Design:

  • Power factor correction

  • Preconfigured supply options for cost-effective deployment

  • Includes all necessary hardware for cabinet integration

Technical Specifications

Specifications

• Dimensions: 127 mm x 508 mm x 254 mm
• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
