Product Description
The NTAI06 from ABB is a dedicated analog input termination module engineered for structured signal interface management in industrial control architectures. It is designed to support ASI and NKAS systems by providing stable and organized termination points for multi-channel analog input wiring.
This unit simplifies field wiring consolidation and improves signal integrity between process instrumentation and control system I/O layers. Its mechanical layout and channel density make it suitable for panel-level integration where space efficiency and reliable signal distribution are required.
Technical Specifications
Model: NTAI06
Manufacturer: ABB
Product Type: Analog Input Termination Module
Channel Configuration
-
Total channels: 16 analog input terminations
-
Signal type: Multi-channel analog signal interface support
-
Purpose: Field signal aggregation and termination
Mechanical Dimensions
-
Depth: 96.52 mm
-
Height: 236.22 mm
-
Width: 218.44 mm
-
Weight: 0.635 kg
Electrical / Interface Characteristics
-
Designed for analog input signal termination
-
Compatible systems: ASI, NKAS
-
Supports structured wiring for control system I/O modules
-
No active signal processing (passive termination architecture)
Environmental & Compliance
-
WEEE category: 5 (small electrical equipment)
-
Operating design: Industrial cabinet installation
-
SCIP reference: fd15e500-2c3b-4af9-a5c7-9b0699d83967
-
HS Code: 85371091 (control and electrical distribution equipment class)
Mechanical Construction
-
Compact DIN-panel oriented design
-
Industrial-grade housing for long service life
-
Optimized for high-density termination wiring layouts
System Function Overview
-
Provides centralized termination for analog input channels
-
Reduces wiring complexity between field devices and control modules
-
Improves signal routing organization in distributed I/O systems
-
Ensures consistent electrical connectivity for multi-channel analog systems
Typical Applications
-
Substation and grid automation systems
-
Process plant analog signal interfacing
-
Distributed control system (DCS) signal termination
-
Retrofit upgrades of legacy analog input architectures
-
Multi-channel instrumentation consolidation panels
FAQ
Q: Does this module perform signal processing?
A: No. The NTAI06 is a passive termination unit designed only for structured signal connection, not signal conditioning.
Q: Which systems is it compatible with?
A: It is designed for ABB ASI and NKAS system architectures.
Q: Can it be used in high-density control cabinets?
A: Yes, its compact footprint is specifically intended for space-optimized panel installations.
