Description
Overview
The NKLS01‑15 Infi‑Net cable is designed for ABB Bailey Net 90 and Infi 90 distributed control systems, providing a stable communication link for high‑integrity industrial networks. Its construction supports reliable data transmission, long service life, and consistent performance in demanding automation environments.
Technical Specifications
General Information
-
Model: NKLS01‑15
-
Manufacturer: ABB
-
Product Type: Infi‑Net Cable (15 ft)
-
Product Range: Bailey Net 90 / Infi 90
-
System Compatibility: DCS
-
Operating Status: Active
Mechanical Data
Electrical & Material Characteristics
-
High‑conductivity copper conductors
-
Robust PVC insulation for mechanical and electrical protection
-
Supports up to 4 twisted pairs for multi‑channel communication
-
Designed for low‑noise signal transmission in industrial networks
Environmental Ratings
-
Operating temperature: −20°C to +60°C
-
IP67 rating for dust‑tight and water‑resistant performance
-
Suitable for harsh industrial environments including moisture‑prone areas
Integration & Application
-
Designed for Infi‑Net communication loops in Bailey Net 90 / Infi 90 systems
-
Suitable for controller‑to‑module and module‑to‑module communication
-
Flexible length supports both compact and extended cabinet layouts
-
Ideal for system expansions, replacements, and maintenance operations
Application Scenarios
-
Distributed control system communication wiring
-
Bailey Net 90 / Infi 90 network expansion
-
Industrial environments requiring rugged, moisture‑resistant cabling
-
Replacement cable for legacy ABB installations
FAQ
Q: Is the NKLS01‑15 compatible with all Infi‑Net modules? A: Yes, it is designed specifically for ABB Infi‑Net communication interfaces.
Q: Can this cable be used outdoors? A: While IP67‑rated, it is primarily intended for indoor industrial environments; outdoor use may require conduit protection.
Q: How many signal pairs does the cable support? A: It supports up to four twisted pairs for multi‑channel communication.
