Description
Product Overview
The ABB INICT13A (Bailey INFI 90) Infi-Net to Computer Transfer Module is a high-capacity interface designed to manage asynchronous communication between host computers and INFI-NET control systems. It supports up to 30,000 point definitions, enabling robust data acquisition, process monitoring, and system control.
Key Features
-
Stores up to 30,000 point definitions for flexible control
-
Supports RS-232-C and SCSI communication via IMMPI01
-
Operates asynchronously with INFI-NET loop for efficient data buffering
-
Direct I/O bus communication with NIS module
-
Interprets host commands for security, time, and configuration control
-
Maintains point tables and exception reports
-
Jumper-configurable DTE/DCE modes via termination modules
Technical Specifications
| Specification |
Detail |
| Manufacturer |
ABB |
| Part Number |
INICT13A |
| Catalog |
Bailey INFI 90 |
| Description |
Infi-Net to Computer Transfer Module |
| Voltage |
5 V |
| Current |
2 A |
| Dimensions (W×H×D) |
27 cm × 36 cm × 7.3 cm |
| Weight |
0.6 kg |
| Communication Ports |
RS-232-C / SCSI via IMMPI01 |
| Memory Capacity |
Up to 30,000 point definitions |
| Interface Modes |
DTE / DCE (jumper selectable) |
Application & Compatibility
The INICT13A module is optimized for Bailey INFI 90 control systems requiring high-volume data exchange and asynchronous operation. It is ideal for power plants, chemical facilities, and other industrial environments where real-time monitoring and control are essential. Compatible with IMMPI01, NTMP01, NIMP01, NIMP02, and NIS modules.
