Description
Product Description
The ABB Bailey INICT01 is a serial communication interface module developed for integration within INFI-90 and Network-90 distributed control systems. It provides a direct link between the INFI-Net control network and external computing devices, enabling data exchange with operator stations, SCADA platforms, or engineering workstations via an RS-232 interface.
This module is designed for legacy system connectivity, allowing modern or semi-modern computer systems to access process data and issue commands through a standardized serial connection. Installed directly into the system rack, it interfaces with the backplane for network communication while exposing a front-accessible DB-9 port for external connection.
The INICT01 is commonly applied in environments where stable and deterministic serial communication is required to maintain interoperability between control networks and supervisory systems.
Technical Specifications
| Parameter |
Description |
| Product Type |
INFI-Net to Computer Communication Module |
| Model |
INICT01 |
| System Compatibility |
ABB Bailey INFI-90, Network-90 |
| Communication Role |
Serial gateway between control network and host computer |
| External Interface |
1 × RS-232-C (DB-9, DCE configuration) |
| Network Interface |
INFI-Net via system backplane |
| Supported Protocols |
INFI-Net serial, RS-232 ASCII communication |
| Data Rate |
50 to 19,200 baud (hardware selectable) |
| Isolation |
Approx. 1500 V (logic-to-network) |
| Memory |
256 KB ROM, 512 KB RAM, 80 KB NVRAM |
| Power Requirements |
+5 VDC @ 4.2 A; +15 VDC @ 40 mA; −15 VDC @ 20 mA |
| Operating Temperature |
Typically 0°C to +70°C (variant dependent) |
| Mounting |
Rack-mounted, occupies dual slots in INFI-90 chassis |
| Dimensions |
Compact module form factor (approx. 70 × 37 × 20 mm board section) |
| Weight |
0.44 kg |
Functional Characteristics
-
Provides RS-232 communication interface for INFI-Net systems
-
Enables integration with external computers, HMIs, and SCADA platforms
-
Configurable baud rate via hardware settings
-
Electrical isolation enhances resistance to industrial noise
-
Integrated memory architecture supports stable data handling
-
Front-panel indicators assist with operational diagnostics
Application Areas
-
Legacy DCS integration with modern monitoring systems
-
Serial communication for operator workstations and engineering PCs
-
Process industries such as power generation and refining
-
Data acquisition and supervisory control environments
-
Retrofit projects requiring RS-232 connectivity
FAQ
What is the primary function of the INICT01 module?
It serves as a serial communication bridge between the INFI-Net control network and external computer systems.
Can it be used with modern PCs?
Yes, provided that appropriate RS-232 interfaces or USB-to-serial converters are used.
Does the module support high-speed communication?
It supports baud rates up to 19.2 kbps, which is typical for legacy serial communication systems.
Is this product still manufactured?
No, it has been discontinued and is typically available through surplus or refurbished inventory.
