Description
Overview
The ABB IMMFP03 Bailey Multifunction Processor Module from the HR Series delivers high-speed processing and reliable automation control. ABB designed this module with a compact 3.5x31.5x17.5 cm form factor and a weight of 0.6 kg, ensuring efficient installation in industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IMMFP03 |
| Module Type |
Bailey Multifunction Processor |
| Manufacturer |
ABB |
| Product Range |
HR Series (Harmony Rack I/O) |
| System Compatibility |
DCS |
| Dimensions |
3.5x31.5x17.5 cm |
| Weight |
0.6 kg |
| Processor Speed |
16 MHz |
| RAM |
128 KB |
| Flash Memory |
128 KB |
| Voltage Range |
12–24 VDC |
| Digital Inputs |
16 channels |
| Digital Outputs |
8 channels |
| Communication Ports |
RS-485, Ethernet |
| Power Consumption |
1.2 W |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| MOQ |
1 |
| Status |
Active |
Functional Description
The ABB IMMFP03 integrates a 16 MHz processor that accelerates control tasks and improves system responsiveness. Engineers benefit from 128 KB RAM and 128 KB Flash memory, which provide sufficient storage for application-specific programming and critical code.
The module supports RS-485 and Ethernet interfaces, enabling seamless communication with industrial networks. ABB equipped the IMMFP03 with 16 digital input channels for precise signal sensing and 8 digital output channels for actuator control, allowing accurate process management.
Its energy-efficient design consumes only 1.2 W, reducing operational costs while maintaining full functionality. The wide voltage range of 12–24 VDC ensures compatibility across diverse industrial environments.
Applications and Compatibility
The ABB IMMFP03 Bailey Multifunction Processor Module suits industries requiring advanced automation, including power generation, chemical processing, and manufacturing. Its integration with HR Series Harmony Rack I/O systems ensures scalability and long-term reliability.
Compatibility with RS-485 and Ethernet communication protocols allows flexible deployment in modern DCS infrastructures. ABB’s engineering quality guarantees dependable performance, making the IMMFP03 a trusted solution for complex industrial control tasks.
