Description
Overview
The ABB IMDSM05 Bailey Infi 90 Digital I/O Module from the HR Series Harmony Rack I/O delivers precise digital signal processing and reliable integration. ABB designed this module with a compact form factor, versatile communication protocols, and durable construction to ensure consistent performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IMDSM05 |
| Module Type |
Bailey Infi 90 Digital I/O Module |
| Manufacturer |
ABB |
| Product Range |
HR Series (Harmony Rack I/O) |
| Dimensions |
3.5 × 31 × 17.5 cm |
| Weight |
0.28 kg |
| HS Code |
8537101190 |
| Origin |
Sweden |
| Condition |
Brand New |
| System |
DCS |
| Channels |
16 digital I/O channels |
| Communication Protocol |
RS-485, Modbus RTU, Ethernet router |
| Operating Temperature |
-40°C to +70°C |
| Construction Material |
Industrial-grade, durable |
Functional Highlights
The ABB IMDSM05 supports 16 digital I/O channels, enabling flexible management of inputs and outputs. Its compact 3.5 × 31 × 17.5 cm design and lightweight 0.28 kg build simplify installation while maintaining robust performance. Engineers benefit from RS-485 and Modbus RTU communication, which ensure seamless integration with automation systems and efficient data exchange.
Energy and Design
ABB engineered the IMDSM05 with durable materials to withstand harsh industrial conditions. Its wide operating temperature range from -40°C to +70°C guarantees reliable functionality in extreme climates. Precision-engineered components enhance operational efficiency and reduce downtime.
Applications and Compatibility
The ABB IMDSM05 Bailey Infi 90 Digital I/O Module supports HR Series Harmony Rack I/O systems and integrates with DCS architectures. Industries such as manufacturing, energy, and process automation rely on this module for reliable signal acquisition, efficient communication, and long-term durability. Its high-density channel configuration makes it ideal for environments requiring extensive monitoring and control.
