Description
Overview
The ABB IMDSM04 Symphony Pulse Input Slave Module from the HR Series (Harmony Rack I/O) delivers precise digital input handling and reliable communication for industrial automation. ABB engineers designed this module with 16 digital channels, ensuring seamless integration and efficient control across complex DCS environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IMDSM04 |
| Module Type |
Pulse Input Slave Module |
| Manufacturer |
ABB |
| Product Range |
HR Series (Harmony Rack I/O) |
| Condition |
Brand New |
| Dimensions |
3.5 × 31 × 17.5 cm |
| Weight |
0.28 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
Sweden |
| System Compatibility |
DCS |
| Communication Service |
Ethernet router |
| Status |
Active |
| Input Channels |
16 digital |
| Interfaces |
Profibus-DP, MODBUS |
| Operating Voltage |
24V DC |
| Environmental Rating |
IP20 |
| Operating Temperature |
-25°C to +60°C |
Design and Performance
ABB constructed the IMDSM04 with durable materials that withstand harsh industrial conditions. Engineers integrated Profibus-DP and MODBUS protocols to ensure versatile connectivity and high-speed data transfer. Its compact dimensions optimize cabinet space, while lightweight construction simplifies installation and maintenance.
Installation and Configuration
The IMDSM04 offers straightforward setup with modular design flexibility. Operators configure the module quickly, ensuring efficient operation and seamless integration into HR Series systems. Its IP20 rating and wide temperature range guarantee stable performance in diverse industrial environments.
Applications and Compatibility
The ABB IMDSM04 Symphony Pulse Input Slave Module supports HR Series automation systems, making it ideal for industries such as manufacturing, energy, and process control. Its 16-channel input capability ensures precise monitoring of digital signals, while its Profibus-DP and MODBUS interfaces enhance communication across industrial networks.
