Description
Overview
The ABB IMCIS01 is a Control I/O Slave Module developed for the Bailey Infi 90 and Net 90 distributed control system platforms. The module serves as an interface between field-level digital devices and central control processors, supporting dependable acquisition and transmission of digital input and output signals in continuous industrial operations.
Designed for process-critical applications, the IMCIS01 handles communication with switches, relays, sensors, solenoids, and actuators while maintaining signal stability in electrically noisy environments.
Main Functional Characteristics
The IMCIS01 module expands system digital I/O capability by processing discrete field signals and transferring operational status information to higher-level controllers within the ABB DCS architecture.
Its configurable signal response settings allow adaptation for both high-speed and standard industrial input applications.
Technical Specifications
| Parameter |
Specification |
| Brand |
ABB |
| Model |
IMCIS01 |
| Product Type |
Control I/O Slave Module |
| System Compatibility |
Bailey Infi 90 / Net 90 |
| Function |
Digital Input and Output Interface |
| Digital Inputs |
Multiple configurable DI channels |
| Digital Outputs |
Relay and actuator control outputs |
| Input Response Selection |
FAST / SLOW selectable via jumpers |
| Jumper Configuration |
J1, J2, J3 |
| Isolation Type |
Galvanic isolation |
| Supported Supply Voltages |
24 VDC, 85 VDC, 125 VDC, 85 VAC, 120 VAC |
| Mounting Options |
Rack installation, panel mounting, DIN rail integration |
| Dimensions |
115 × 90 × 25 mm |
| Weight |
0.25 kg |
Performance Features
• Reliable digital signal acquisition and output control
• Electrical isolation improves noise resistance and protects control circuits
• Flexible AC and DC supply compatibility
• Compact module footprint for high-density cabinet layouts
• Selectable signal filtering for different field response requirements
• Stable operation in power generation and heavy industrial facilities
• Designed for long-term continuous control applications
Industrial Applications
The ABB IMCIS01 is commonly installed in:
• Power station control systems
• Petrochemical automation facilities
• Water treatment and utility systems
• Manufacturing process control networks
• Turbine and auxiliary equipment monitoring
• Relay and actuator interface panels
• Distributed plant control cabinets
System Integration
This module is intended for use within ABB Bailey Infi 90 and Net 90 environments, where it functions as a slave communication interface between field instrumentation and supervisory controllers.
Its architecture supports dependable digital status monitoring and command execution in distributed automation systems.
FAQ
What is the primary purpose of the IMCIS01 module?
The module is used for digital input collection and digital output control in ABB Infi 90 and Net 90 distributed control systems.
Can the module operate with both AC and DC power sources?
Yes. The IMCIS01 supports multiple supply options including 24 VDC, 85 VDC, 125 VDC, 85 VAC, and 120 VAC.
Why is galvanic isolation important in this module?
Galvanic isolation helps reduce electrical noise interference and protects sensitive control electronics from voltage disturbances between field devices and controllers.
Does the module support configurable signal response timing?
Yes. Input processing speed can be configured as FAST or SLOW using onboard jumper settings.
