The ABB IEFAN01 Fan Assembly is a forced-air cooling module designed for Bailey Infi 90 and Net 90 control system cabinets. It is engineered to maintain stable internal temperature conditions by providing continuous airflow across power supplies, processor modules, and I/O racks.
This multi-fan cooling system is typically installed in high-density control enclosures where thermal management is critical to system reliability and long-term electronic performance.
Cooling System Function
The IEFAN01 operates as an integrated rack cooling solution, distributing airflow evenly across installed modules to prevent localized overheating. It is commonly deployed in control cabinets where continuous operation and heat dissipation are essential.
Its design supports high-reliability environments such as power generation, refinery automation, and large-scale process control systems.
Technical Specifications
| Parameter |
Specification |
| Brand |
ABB |
| Model |
IEFAN01 |
| Product Type |
Fan Assembly |
| System Compatibility |
Bailey Infi 90 / Net 90 |
| Electrical Rating |
120 VAC |
| Frequency |
50/60 Hz |
| Fan Configuration |
6-Fan Array |
| Cooling Method |
Forced Air Circulation |
| Application |
Rack and Cabinet Thermal Management |
| Mounting Style |
Control Cabinet Integration |
| Airflow Capacity |
Approx. 50 CFM (industry reference) |
| Power Consumption |
Low power design (varies by configuration) |
| Noise Level |
Low acoustic operation (~35 dB(A) reference design) |
| Dimensions |
19.0 × 2.0 × 14.0 in |
| Net Weight |
8.2 kg |
| Country of Origin |
United States |
| Product Category |
Cooling Assembly |
Design Characteristics
The ABB IEFAN01 uses a multi-fan configuration to ensure uniform airflow distribution across electronic modules. The design minimizes thermal hotspots and supports continuous operation of critical control hardware.
Its compact rack-compatible form factor allows straightforward installation within standard Infi 90 cabinet assemblies.
Typical Applications
The fan assembly is widely used in:
-
Distributed control system cabinets
-
Power generation control panels
-
Petrochemical automation enclosures
-
Industrial process control racks
-
High-density electronic module installations
-
Mission-critical control environments requiring thermal stability
System Role
Within ABB Infi 90 and Net 90 architectures, the IEFAN01 functions as a dedicated thermal management component, ensuring that control electronics operate within safe temperature thresholds during continuous industrial operation.
