Description
Overview
The ICSM06A6 (FPR3350601R1062) analog I/O remote unit is part of ABB’s Procontic CS31 family, designed to extend distributed I/O capabilities in compact automation architectures. It provides precise analog signal acquisition and output control, supporting stable and deterministic operation in process‑driven environments.
Technical Specifications
| Parameter |
Specification |
| Model |
ICSM06A6 (FPR3350601R1062) |
| Product Type |
Analog I/O Remote Unit |
| Brand |
ABB |
| Product Series |
Procontic CS31 |
| Function |
Remote analog input/output processing |
| Analog Inputs |
6 channels |
| Analog Outputs |
6 channels |
| Input/Output Type |
Voltage or current (varies by configuration; verify per system manual) |
| Power Supply |
12 V DC ±10% |
| Operating Temperature |
–25°C to +60°C |
| Protection Rating |
IP20 (cabinet‑protected environments) |
| Communication |
CS31 system bus (DeviceNet/EtherCAT reference removed; not applicable to this module) |
| Dimensions |
12.2 × 9.2 × 6.3 cm |
| Weight |
0.28 kg |
| Installation |
DIN‑rail or panel mounting |
| Country of Origin |
Sweden |
| HS Code |
8537101190 |
| Availability |
In stock |
| Condition |
New |
Functional Description
The ICSM06A6 module provides remote analog signal handling for Procontic CS31 controllers. Its six input channels allow accurate measurement of process variables such as temperature, pressure, and flow, while its six output channels support precise actuation of control elements like valves and drives.
The module’s internal circuitry ensures stable signal conditioning, low noise, and reliable conversion accuracy across its full operating temperature range. Designed for distributed architectures, it reduces wiring complexity and improves system scalability.
Its compact enclosure and low power consumption make it suitable for installations with limited cabinet space. The module integrates seamlessly into CS31 networks, enabling synchronized data exchange and consistent control performance.
Application Scenarios
-
Distributed analog I/O expansion for Procontic CS31
-
Remote measurement and actuation in process industries
-
Compact control panels requiring mixed analog I/O
-
Replacement module for legacy CS31 installations
-
Systems requiring precise analog signal conditioning
Similar Model Comparison
| Model |
Function |
Typical Use |
| ICSM06A6 |
6 AI / 6 AO |
Mixed analog I/O processing |
| ICSM04A4 |
4 AI / 4 AO |
Smaller analog I/O applications |
| DCSM04 |
Digital I/O |
Remote digital signal handling |
FAQ
Q: Does the ICSM06A6 support DeviceNet or EtherCAT? A: No. It communicates via the Procontic CS31 system bus.
Q: Can the module be hot‑swapped? A: No. Power must be removed before installation or replacement.
Q: Are the analog channels configurable for voltage or current? A: Yes, but configuration depends on the specific system setup and must follow ABB documentation.
