Description
Overview
The ICSC08L1 FPR3319101R1082 digital output module is part of ABB’s Procontic CS31 product line, designed to provide dependable output signal control within DCS‑based automation systems. Its compact construction, stable electrical performance, and robust communication capabilities make it suitable for both new installations and system expansions.
Functional Characteristics
This module offers eight independent digital output channels engineered for precise switching and reliable field‑level control. The hardware design supports clean signal transitions and consistent operation in environments where electrical noise and temperature fluctuations are common.
The ICSC08L1 FPR3319101R1082 integrates smoothly into CS31 networks and supports Modbus RTU/TCP communication, enabling flexible deployment across distributed control architectures. Its enclosure and internal layout are optimized for durability, providing resistance to dust and moisture when installed in appropriately rated cabinets.
Low power consumption and straightforward wiring simplify installation and maintenance. The module’s electrical characteristics and mechanical design make it a practical choice for applications requiring fast response times and stable digital output performance.
Technical Specifications
| Parameter |
Value |
| Model / Part Number |
ICSC08L1 FPR3319101R1082 |
| Product Type |
Digital Output Module |
| Manufacturer |
ABB |
| Product Series |
Procontic CS31 |
| System Compatibility |
DCS / CS31 |
| Condition |
Brand New |
| Country of Origin |
Sweden |
| Weight |
0.28 kg |
| Dimensions |
12.2 × 9.5 × 6.3 cm |
| HS Code |
8537101190 |
| Output Channels |
8 Digital Outputs |
| Operating Voltage |
24 V DC |
| Communication |
Modbus RTU / Modbus TCP |
| Environmental Protection |
Dust and moisture‑resistant housing (cabinet‑dependent) |
| Operating Temperature |
Suitable for harsh industrial environments |
| Availability |
In Stock |
| Minimum Order |
1 Unit |
| Operational Status |
Active |
Application Scenarios
-
Machine control and sequencing
-
Process equipment actuation
-
Distributed I/O expansion in CS31 systems
-
Industrial monitoring and switching tasks
-
System modernization and DCS upgrades
FAQ
Q: Does this module support both Modbus RTU and TCP? Yes, it is compatible with both protocols for flexible integration.
Q: Can it be used as a replacement for older CS31 output modules? In most cases, yes. System wiring and configuration should be reviewed before installation.
Q: Is the module suitable for harsh environments? The module itself is robust, and when installed in a properly rated enclosure, it performs reliably in demanding conditions.
