Description
Overview
The HIEE300910R0001 UFC092 BE01 binary input module is part of ABB’s UNITROL® 5000 excitation platform. It is engineered to acquire digital field signals with high accuracy and fast response, supporting reliable monitoring and protection functions in generator excitation and DCS‑based control systems.
Technical Specifications
| Parameter |
Specification |
| Model / Part Number |
HIEE300910R0001 UFC092 BE01 |
| Product Type |
Binary Input Module |
| Manufacturer |
ABB |
| Product Range |
UNITROL® 5000 |
| System Compatibility |
DCS / Excitation systems |
| Input Voltage |
24 VDC |
| Input Type |
Isolated digital inputs |
| Terminal Type |
Screw terminal block |
| Operating Temperature |
–25°C to +85°C |
| Dimensions |
40.3 × 12.6 × 5.8 cm |
| Weight |
1.04 kg |
| Country of Origin |
Sweden |
| Condition |
Brand New |
| Availability |
In Stock |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Lifecycle Status |
Active |
Functional Description
The HIEE300910R0001 UFC092 BE01 module captures binary field signals and transfers them to the UNITROL 5000 control system for processing. Its fast input response ensures accurate detection of switching events, alarms, and protection triggers.
The module’s electrical design includes input isolation and noise‑suppression components, enabling stable operation in environments with high electromagnetic interference. Its screw‑terminal interface simplifies wiring and ensures secure electrical connections for long‑term reliability.
With a wide operating temperature range and robust mechanical construction, the UFC092 BE01 is suitable for installation in harsh industrial environments, including power plants, substations, and heavy‑industry facilities.
Application Areas
-
UNITROL 5000 excitation systems
-
Generator protection and monitoring
-
Digital signal acquisition for DCS platforms
-
Industrial automation requiring fast binary input processing
-
Replacement of legacy ABB binary input modules
FAQ
Q: Can the UFC092 BE01 be used with earlier UNITROL systems? A: It is designed for UNITROL 5000 but may integrate with earlier systems if the rack and firmware support the module’s input specifications.
Q: Does the module require calibration? A: No calibration is typically required. Inputs are recognized automatically by the excitation controller.
Q: Is the module suitable for high‑temperature installations? A: Yes. It supports operation up to +85°C, making it suitable for demanding environments.
