Description
ABB DSQC503 AXIS COMPUTER BOARD
The ABB DSQC503 3HAC3619-1, also cataloged as the DSQC503 Axis Computer Board, operates as a dedicated hardware component for axis control signal processing within ABB industrial robot controller platforms.
Hardware Specifications
Parameter
Specification
Model
DSQC503 3HAC3619-1
Brand
ABB
Product Type
Axis Computer Board
Origin
Sweden
Weight
2.36 kg
Dimensions
Estimated shipping size: 14.5 cm x 18 cm x 15 cm
Operating Temp
-10 deg C to 55 deg C
Storage Temp
-25 deg C to 70 deg C
Humidity
5% to 95% non-condensing
Input Voltage
Typically 24 VDC
Tariff Code
8537101190
ABB Industrial Control Architecture and Axis Processing
The DSQC503 axis computer board executes axis-related processing functions inside ABB robot control architectures. It handles internal communication between motion control software and connected drive hardware. In addition, the board processes control data required for coordinated robot axis movement and feedback handling.
For ABB controller systems, the hardware supports industrial control integration through internal backplane communication. Therefore, correct firmware compatibility and controller configuration are required before replacement or commissioning.
The DSQC503 follows ABB PLC and robot automation design principles, including backplane bus communication velocity handling, firmware flash compatibility, and I/O density scaling within supported controller configurations.
Frequently Asked Questions
Q: Does the ABB DSQC503 support hot-swap replacement during controller operation? A: The DSQC503 is a controller hardware module. Hot-swap operation depends on the specific ABB robot controller architecture and system configuration. Power isolation is required before physical replacement unless the controller manual specifies otherwise.
Q: What input voltage does the DSQC503 require? A: The available technical data specifies a typical input voltage of 24 VDC. The installed controller power distribution must match ABB system requirements.
Q: Which environmental conditions apply to DSQC503 installation? A: The specified operating range is -10 deg C to 55 deg C with 5% to 95% non-condensing humidity. Installation should prevent condensation, contamination, and excessive vibration.
Field Installation Guidelines
Verify the ABB controller model and firmware compatibility before installing the DSQC503 3HAC3619-1 board.
Disconnect controller power before removing or inserting the module.
Inspect board connectors and backplane contacts for contamination or mechanical damage.
Install the module according to ABB mechanical alignment requirements to prevent connector stress.
Maintain proper cable routing to reduce electromagnetic interference near signal and power conductors.
Confirm grounding continuity between the controller chassis and protective earth connection before startup.
Perform controller diagnostics after installation to verify axis communication and module recognition.
