The ABB DSQC 658 (3HAC025779-001) is a specialized communication interface module designed for integration within ABB robotic control systems. This DeviceNet Master/Slave (M/S) single-channel unit facilitates robust fieldbus communication, allowing the robot controller to exchange data with peripheral devices, sensors, and actuators on a DeviceNet network.
Features
- Supports DeviceNet Master/Slave functionality for versatile network configuration.
- Designed for seamless integration with ABB robot control cabinets.
- Compact hardware footprint optimized for rack-mounted installation.
- Reliable data exchange for industrial automation environments.
Technical Specifications
| Product ID |
3HAC025779-001 |
| Model |
DSQC 658 |
| Function |
DeviceNet M/S Single |
| Net Weight |
0.142 kg |
| Customs Tariff Number |
85389091 |
Installation Guidelines
- Ensure the robot controller power is fully disconnected before installing or removing the DSQC 658 module.
- Handle the module using proper ESD (electrostatic discharge) protection measures to prevent damage to internal circuitry.
- Verify that the module is firmly seated in the designated slot and secured according to the robot cabinet documentation.
- Use shielded cables for DeviceNet communication to minimize EMI interference in high-noise industrial environments.
- Check that all network termination resistors are correctly applied at the end of the DeviceNet bus segment.
FAQ
What is the primary function of the ABB DSQC 658?
The DSQC 658 serves as a DeviceNet communication interface, enabling the ABB robot controller to act as either a master or a slave node within a DeviceNet fieldbus network.
Is this module compatible with all ABB robots?
This module is specific to ABB controller architectures supporting the DSQC 658 hardware. Please cross-reference your specific robot controller manual or the 3HAC025779-001 part number against your current system configuration to ensure compatibility.
