Product Overview
The ABB DSDP150 57160001-GF Pulse Encoder Input Module delivers precise pulse counting and positioning for advanced automation systems. ABB designed this unit for MasterPiece controllers, ensuring high-resolution measurement and reliable performance in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DSDP150 57160001-GF |
| Manufacturer |
ABB |
| Module Type |
Pulse Encoder Input Module |
| Product Range |
MasterPiece |
| Condition |
Brand New |
| Dimensions |
2.1 × 25 × 24.5 cm |
| Weight |
0.38 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
Sweden |
| System |
DCS |
| Communication Interface |
Ethernet Router, MODBUS RTU |
| Status |
Active |
| Enclosure Protection |
IP65 dust and splash resistant |
| Construction Material |
High-quality aluminum |
| Power Supply |
12V DC |
Functional Description
The ABB DSDP150 57160001-GF features advanced microprocessor technology that ensures accurate pulse counting and positioning. Its compact 2.1 cm thickness and 0.38 kg weight simplify installation while maintaining durability. Engineers benefit from IP65 protection, which safeguards against dust and water splashes, ensuring reliable operation in harsh environments. The module supports MODBUS RTU communication, enabling seamless integration and reducing programming complexity.
Applications and Compatibility
The ABB DSDP150 57160001-GF integrates smoothly into ABB MasterPiece systems and connects with diverse automation networks. Manufacturers deploy this module in robotics, heavy machinery, and precision manufacturing processes. Its high-resolution pulse measurement enhances machine accuracy, while aluminum construction ensures long-term durability with minimal maintenance.
Key Advantages
-
Compact dimensions optimize cabinet space utilization.
-
Lightweight design simplifies installation and handling.
-
IP65 enclosure ensures protection against dust and water splashes.
-
MODBUS RTU communication simplifies connectivity and integration.
-
High-resolution pulse counting improves machinery accuracy and efficiency.
