Description
Product Overview
The ABB DO801 3BSE020510R1 Digital Output Module ensures fast and accurate signal transmission with a response time of ≤1ms. ABB designed this unit for S800 I/O systems, combining compact dimensions with robust performance to meet demanding industrial automation requirements.
Technical Specifications
| Parameter |
Value |
| Model Number |
DO801 3BSE020510R1 |
| Manufacturer |
ABB |
| Module Type |
Digital Output 24V 16 ch |
| Product Range |
S800 I/O |
| Condition |
Brand New |
| Dimensions |
9.3 × 13.6 × 5.1 cm |
| Weight |
0.2 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
Sweden |
| System |
DCS |
| Communication Interface |
Ethernet Router |
| Status |
Active |
| Current Rating |
10A |
| Input Resistance |
5kΩ |
| Response Time |
≤1ms |
| Operating Temperature |
-20°C to +70°C |
| Certifications |
CE, UL, CSA |
Functional Description
The ABB DO801 3BSE020510R1 delivers reliable control with a 10A current rating, enabling it to handle heavy-duty loads. Its compact 9.3 cm width and lightweight 0.2 kg design simplify installation while maximizing cabinet space efficiency. Engineers benefit from its 5kΩ input resistance, which ensures compatibility with a wide range of sensors and detectors. The rugged construction supports operation across extreme temperatures from -20°C to +70°C, maintaining consistent performance in diverse industrial environments.
Applications and Compatibility
The ABB DO801 3BSE020510R1 integrates seamlessly into ABB S800 I/O systems and connects with DCS networks. Manufacturers deploy this digital output module in energy plants, automated production lines, and heavy machinery applications. Its certifications (CE, UL, CSA) guarantee compliance with international safety standards, making it a trusted solution for global automation projects.
Key Advantages
-
Compact dimensions optimize cabinet space utilization.
-
Lightweight design simplifies installation and handling.
-
≤1ms response time ensures precise control signal transmission.
-
10A current rating supports demanding industrial loads.
-
Certified to CE, UL, and CSA for global safety compliance.
