Description
Product Overview
The ABB DO610 3BHT300006R1 Digital Output Module provides precise and reliable signal control for industrial automation. ABB designed this module for S600 I/O systems, ensuring robust performance, fast switching, and seamless integration into demanding environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
DO610 3BHT300006R1 |
| Manufacturer |
ABB |
| Module Type |
Digital Output Module |
| Product Range |
S600 I/O |
| Condition |
Brand New |
| Dimensions |
4 × 26 × 27.2 cm |
| Weight |
1.16 kg |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
Sweden |
| System |
DCS |
| Communication Interface |
Ethernet Router, Modbus RTU |
| Status |
Active |
| Output Channels |
8 |
| Current Capacity |
2A per channel |
| Switching Speed |
1ms |
| Operating Temperature |
-20°C to +60°C |
| Construction Material |
Aluminum alloy |
Functional Description
The ABB DO610 3BHT300006R1 features 8 output channels, each capable of handling up to 2A, ensuring efficient control of actuators and sensors. Its compact 4 cm thickness and 1.16 kg weight simplify installation while maintaining durability. Engineers benefit from its 1ms switching speed, which guarantees precise timing for high-speed applications. The module supports Modbus RTU communication, enabling seamless connectivity with industrial networks. Its aluminum alloy construction provides strength while keeping the design lightweight.
Applications and Compatibility
The ABB DO610 3BHT300006R1 integrates seamlessly into ABB S600 I/O systems and connects with DCS networks. Manufacturers deploy this digital output module in energy plants, automated production lines, and heavy machinery applications. Its wide operating temperature range and panel-mount style design make it suitable for harsh environments requiring reliable performance.
Key Advantages
-
8 output channels with 2A capacity each.
-
Fast 1ms switching speed ensures precise timing.
-
Compact dimensions optimize cabinet space utilization.
-
Lightweight aluminum alloy construction enhances durability.
-
Modbus RTU support improves system compatibility and integration.
