Description

Product Overview

The ABB CP800 Communication Processor Module is a high-performance interface designed for Symphony® Plus SD Series controllers. It facilitates seamless communication between the HC800 controller and the PN800 Ethernet-based plant network, enabling real-time data exchange and system coordination.

Technical Specifications

Key Features

• Ethernet-Based Communication: Connects HC800 controller to PN800 plant network

• Advanced Control Support: Executes over 30,000 function blocks with flexible configuration

• Fast Loop Execution: Controls 5,000+ I/O points in under 250 ms

• Multi-I/O Compatibility: Supports SD Series, Harmony Rack, and S800 subsystems

• Online Configuration: Enables runtime updates with downloadable firmware

• Segmented Task Execution: Up to 8 tasks with cycle times down to 1 ms

• Redundant Communication Bus: Peer-to-peer updates in less than 100 ms

Specifications

• Dimensions: 243.84 mm x 73.66 mm x 170.18 mm
• Brand: ABB

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
